PLAN 137-288
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 68' 6"
Height : 37'
Width : 62' 4"
Area
First Floor: 2214 sq/ft height 10'
Second Floor: 1063 sq/ft height 10'
Ceiling
Main Ceiling : 9'
Roof
Roof Framing : Stick
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Shingle
Framing : 2 x 6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Sunroom
Unfinished Future Space
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Screened Porch
Rooms
Bedroom 2:
width 13' 6" x depth 12' 8"
Bedroom 3:
width 13' 6" x depth 12' 8"
Bedroom 4:
width 15' x depth 14' 8"
Breakfast:
width 12' x depth 10' 6"
Dining Room:
width 13' 8" x depth 12' 8"
Foyer:
width 7' x depth 18' 4"
Garage:
575 sq/ft width 22' 6" x depth 24'
Great Room:
width 22' 4" x depth 16'
Kitchen:
width 13' 4" x depth 14'
Living Room:
width 13' 10" x depth 12' 8"
Master Bath:
width 11' 4" x depth 14' 8"
Master Bedroom:
width 15' 6" x depth 17' 4"
Porch Front:
362 sq/ft width 36' 2" x depth 10'
Porch Screened:
260 sq/ft width 21' 8" x depth 10' 8"
Rec. Room:
460 sq/ft width 22' 6" x depth 19' 4"
Utility Room:
width 6' 4" x depth 10' 10"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
Plans are typically drawn to ¼” scale and include:
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. Some plans that do not include an electrical plan may have it available for an additional fee.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Rendering(s): Designer’s rendering of front elevation
Plan Set
$782.00
$858.50
$1020.00
$1020.00
$680.00
Foundation
$0.00
$0.00
Additional Options
$46.75
$140.25
$335.75
$33.15
$140.25
$46.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
