PLAN 1019-15
Key Specs
3297
sq ft
5
Beds
3
Baths
1
Floors
3
Garages
Cost to Build Reports Only $9.99 for a Limited Time! Use Code CTB2021
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 1019-15
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
First impressions are best resolved when further observations dispel assumptions. Sometimes, "I stand corrected", can be liberating when you allow yourself an open mind. Discovering something that you thought was not possible is the cornerstone of reality. Each of these statements characterize this medium sized home. With its' "lives big" attitude it redefines what typical small footprint homes can be.
Full Specs & Features
Height : 25' 8"
Width : 70'
Garage: 719 sq/ft height 10'
Roof Framing : Truss
Roof Type : Composition
Framing : Block
Formal Dining Room
Formal Living Room / Parlor
Walk In Closet
Kitchen Island
Main Floor Laundry
Mud Room
Covered Rear Porch
Bedroom 2:
168 sq/ft width 13' 8" x depth 12' 4"
Bedroom 3:
143 sq/ft width 12' 4" x depth 11' 8"
Bedroom 4:
128 sq/ft width 11' 8" x depth 11'
Bedroom 5:
143 sq/ft width 11' x depth 13'
Breakfast:
157 sq/ft width 14' 4" x depth 11'
Covered Porch:
218 sq/ft width 16' x depth 13' 8"
Dining Room:
160 sq/ft width 13' x depth 12' 4"
Family Room:
320 sq/ft width 20' x depth 16'
Garage:
702 sq/ft width 23' 8" x depth 29' 8"
Kitchen:
185 sq/ft width 14' 8" x depth 12' 8"
Laundry Room:
72 sq/ft width 8' x depth 9'
Living Room:
156 sq/ft width 12' x depth 13'
Master Bathroom:
150 sq/ft width 11' x depth 13' 8"
Master Suite:
306 sq/ft width 20' x depth 15' 4"
Master Walk-In Closet:
144 sq/ft width 16' x depth 9'
Porch - Front:
154 sq/ft width 7' x depth 22'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| Reproducible Set
: $1250.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set
: $2000.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
| Block: $0.00 |
Block |
Additional Options
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets
: $750.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
