PLAN 119-432

European Exterior - Front Elevation Plan #119-432
European Exterior - Rear Elevation Plan #119-432
European Exterior - Front Elevation Plan #119-432
European Interior - Dining Room Plan #119-432
Great Room
Great Room
European Interior - Kitchen Plan #119-432
European Exterior - Front Elevation Plan #119-432
European Exterior - Rear Elevation Plan #119-432
European Exterior - Other Elevation Plan #119-432
European Exterior - Front Elevation Plan #119-432

Key Specs

sq ft





Select Plan Set Options

What's included?
NOW $1417.50
You save $157.50
(10% savings)
Sale ends soon!
Also order by phone: 1-800-447-0027
Cost-to-Build Estimates
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 119-432

Key Specs

sq ft





This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Full Specs & Features

Depth : 68'
Height : 40'
Width : 143'
Basement : 1707 sq/ft
Garage : 1462 sq/ft
Main Floor : 2201 sq/ft
Upper Floor : 1101 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Lower Ceiling : 9'
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Primary Pitch : 12/12
Roof Framing : TJIs
Secondary Pitch : 10/12
Exterior Wall Framing
Framing : 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Play Flex Room
Garage Features
Carport Porte Cochere
Side Entry Garage
Outdoor Spaces
Covered Rear Porch

2-Car Garage:

width 24' x depth 24'

3 car garage:

width 35' 6" x depth 23'

Bathroom 2:

width 5' x depth 10'

Bathroom 3:

width 6' x depth 7' 6"

Bathroom 4:

width 8' 6" x depth 5'

Bedroom 2:

width 12' x depth 13'

Bedroom 3:

width 12' x depth 13'

Bedroom 4:

width 13' 6" x depth 13'

Bedroom 5:

width 12' x depth 16' 6"


width 16' x depth 13'

Family Room:

width 17' x depth 18' 6"

Game Room:

width 16' x depth 18'

Great Room:

width 17' x depth 22' 6"

Gym/Bedroom 6:

width 11' x depth 15'


width 19' x depth 17' 6"


width 15' x depth 11'

Master Bath:

width 16' 6" x depth 21'

Master Closet:

width 10' x depth 11'

Master Suite:

width 15' x depth 22' 6"

Mech Room:

width 22' x depth 12' 6"


width 4' x depth 4'


width 13' x depth 16'

Porte Cochere:

width 32' x depth 35' 6"

What's Included In This Plan Set

  • Cover Sheet: The cover sheet features an elevation of the home, sheet number index for the plan, and contact information.
  • Foundation: These drawings will detail and illustrate the foundation of the home, exterior and interior footings to support the floors and structure above. If a basement is purchased, it will show the stairs, bearing walls, and basement windows and doors.
  • First Floor Plan: This page is drawn to ¼”=1’-0” scale and includes exterior dimensions to build the home. The notes are precise directions for your builder. Important features such as built-ins, niches, and appliances are noted. Doors and windows are identified and specific sizing can be found on window and door schedules. *Framing is not included.
  • Second Floor Plan: The second floor includes stair details. Often the reflective roof detail is shown legibly over the second floor plan. This is helpful for the framing contractor. *Framing is not included.
  • Lighting and Electrical: On this sheet you have a schematic of the lights, electrical plugs, phone location, and code items such as smoke detectors. It is common place to build with your builder and/or electrician before the work starts to review this plan. Careful planning can make your home special and convenient for your family.
  • Second Floor Lighting: The same details as provided for the first floor.
  • Front and Rear Elevations: The front and rear elevations may be on separate pages depending on the size of the house. This page comes with exterior dimensions and notes required to complete construction. This is where the windows, doors, and interior trim details are illustrated, as well as wall heights, roof pitches and ridge heights.
  • Right and Left Elevations: The right and left elevations provide the same details as the front and rear elevations.
  • Roof Plan: This drawing, usually at ¼”=1’-0” scale, will be a bird’s eye view of the home. It will show the ridges, hips, and valleys. This page will show a beautifully designed roof.*Framing is not included.
  • Cross-Sections: Sections are used to further describe any architectural intent necessary for the builder or framer. This drawing will illustrate important changes in the floor, ceiling, and roof heights.
  • Cabinet Elevations*: Cabinet elevations are provided with your plans, and like the electrical plan, they are mainly a guide for estimating purposes. Cabinets are an area that is easy to customize and your builder or cabinet maker will work with you early on in the process to ensure that the correct cabinets are specified. Archival Designs believes cabinets should reflect your taste and budget. After framing and sheet rock installation sizes of walls may change slightly. The cabinet maker must take as built measurements to properly size your cabinets. **NOTE: The majority of house plans will include cabinet elevations in construction set; however, not all will include.
  • General Notes: Separate sheets that provide standard construction notes, in addition included are the details required to comply with International Residential Code (IRC) & Southern Building Code (SBC).
