PLAN 17-2497
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 77' 2"
Height : 30' 5"
Width : 81' 4"
Area
Bonus: 747 sq/ft
First Floor: 3415 sq/ft
Garage: 1110 sq/ft
Ceiling
Ceiling Details :
Main Ceiling : 9'
Roof
Primary Pitch : 10:12
Roof Framing : Stick
Roof Load : 45
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone Veneer
Framing : 2x4
Insulation : R-13
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Mud Room
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
width 14' 4" x depth 14'
Bedroom 3:
width 14' 4" x depth 13' 6"
Bonus:
747 sq/ft width 20' 10" x depth 21' 4"
Breakfast:
width 14' x depth 11' 4"
Dining:
width 14' x depth 12'
Great Room:
width 21' 6" x depth 19' 2"
Grilling Porch:
185 sq/ft width 21' 6" x depth 8' 6"
Guest Suite:
width 11' 8" x depth 13'
Kitchen:
width 14' x depth 16' 10"
Laundry:
width 20' 10" x depth 9' 4"
Master Bath:
width 11' 6" x depth 18' 6"
Master Bedroom:
width 17' 6" x depth 15'
Master Closet:
width 13' x depth 8'
Porch Front:
width 47' x depth 0"
