Key Specs
3700
sq ft
4
Beds
3.5
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBBF (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 429-339
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 88' 3"
Height : 33' 6"
Width : 73' 3"
Area
Bonus: 540 sq/ft height 8'
First Floor: 2390 sq/ft height 8'
Second Floor: 1310 sq/ft height 8'
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Main Floor Laundry
Unfinished Future Space
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bathroom 2:
123 sq/ft width 14' 6" x depth 8' 6"
Bathroom 3:
46 sq/ft width 8' 6" x depth 5' 6"
Bedroom 2:
199 sq/ft width 14' 3" x depth 14'
Bedroom 2 Closet:
16 sq/ft width 7' 3" x depth 2' 3"
Bedroom 3:
210 sq/ft width 16' 6" x depth 12' 9"
Bedroom 3 Closet:
45 sq/ft width 8' 3" x depth 5' 6"
Bonus Room - Finished:
431 sq/ft width 14' 3" x depth 30' 3"
Breakfast:
135 sq/ft width 10' x depth 13' 6"
Coat Closet:
8 sq/ft width 3' 6" x depth 2' 6"
Dining Room:
221 sq/ft width 16' 9" x depth 13' 3"
Family Room:
284 sq/ft width 16' 9" x depth 17'
Foyer:
91 sq/ft width 7' 6" x depth 12' 3"
Garage:
534 sq/ft width 22' 3" x depth 24'
Kitchen:
186 sq/ft width 12' x depth 15' 6"
Laundry Room:
92 sq/ft width 10' 3" x depth 9'
Linen Closet:
8 sq/ft width 4' 3" x depth 2'
Master Bathroom:
206 sq/ft width 8' 6" x depth 24' 3"
Master Bedroom:
303 sq/ft width 15' x depth 20' 3"
Master Closet:
75 sq/ft width 10' 9" x depth 7'
Master Closet Two:
55 sq/ft width 8' 6" x depth 6' 6"
Porch - Front:
31 sq/ft width 7' 6" x depth 4' 3"
Porch - Left:
58 sq/ft width 9' x depth 6' 6"
Porch - Rear:
157 sq/ft width 24' 3" x depth 6' 6"
Powder Room:
35 sq/ft width 5' 9" x depth 6' 3"
Study:
192 sq/ft width 13' 6" x depth 14' 3"
Wet Bar:
13 sq/ft width 3' x depth 4' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$720.00
$800.00
$1000.00
$1000.00
$640.00
Foundation
$0.00
$120.00
$120.00
Framing
$0.00
Additional Options
$52.00
$80.00
$31.20
$160.00
$68.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
