PLAN 40-238
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 70' 8"
Height : 31' 8"
Width : 71' 6"
Area
First Floor: 2981 sq/ft height 10'
Garage: 739 sq/ft height 10'
Porch: 294 sq/ft
Second Floor: 855 sq/ft height 9'
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Great Room Living Room
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
More
Jack & Jill Bath
Rooms
Bedroom 2:
140 sq/ft width 11' 8" x depth 12'
Bedroom 3:
141 sq/ft width 11' 9" x depth 12'
Bedroom 4:
175 sq/ft width 12' 6" x depth 14'
Bedroom 5:
169 sq/ft width 13' x depth 13'
Dining Room:
369 sq/ft width 12' x depth 30' 9"
Family Room:
506 sq/ft width 23' x depth 22'
Game Room:
255 sq/ft width 17' x depth 15'
Garage:
668 sq/ft width 21' 9" x depth 30' 9"
Kitchen:
263 sq/ft width 17' x depth 15' 6"
Master Bedroom:
408 sq/ft width 21' 6" x depth 19'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$905.00
$995.00
$1080.00
$1655.00
$805.00
Foundation
$0.00
$0.00
$0.00
Additional Options
$100.00
$50.00
$100.00
$39.00
$200.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
