PLAN 930-538

Photographs may show modified designs.

Save
Questions? Get Personalized Help
Home  >  Style  >  Contemporary

Key Specs


Plan Sq Ft

3882
sq ft

Plan Bedrooms

5
Beds

Plan Bathrooms

4.5
Baths

Plan Floors

2
Floors

Plan Garages

3
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Additional Construction Sets
$58.50/each
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design
$148.50
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide
$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Subtotal
NOW $2376.00
You save $264.00 (10% savings)
Sale ends soon!
Best Price Guaranteed*

Also order by phone: 1-800-447-0027
Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Hours:
Mon - Fri 8:30 - 8:30 (EDT)
NEW!  Sat - Sun 10 - 7 (EDT)

See our Terms & Conditions and Privacy Policy.

PLAN 930-538

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


Sophisticated yet relaxed charm is yours with this home design. Its narrow shape contains 3882 square feet of living area for your enjoyment. Even with its compact footprint, all the major rooms have expansive views to the back of the home - a big benefit whether overlooking the ocean, lake, golf course or stream. The exterior styling reflects a Caribbean flair with its metal hipped rooflines, stucco wall surfaces and bracketed balconies and shuttered eaves. The deep entry placed between the two garages gives great presence and protection. Guests can be greeted from the second floor balcony. Once inside, you enter the Foyer with its beamed ceiling and staircase. Just a little beyond is a wet bar as you approach the Great Room. Just beyond that is the entry into the Main Suite and the Study. The Study with its angled entrance gives interaction with the Great Room and the view beyond. It can also function as a Media Room as well. The openness of the Great Room to the Kitchen and Dining lends to a very grand and spacious feel. The Kitchen has a large walk-in pantry and the Dining Room features cornerless sliding glass doors that give an outdoor dining sensation. The “L” shaped Veranda with its outdoor kitchen makes for great outdoor entertainment. The Main Suite is entered via a private foyer and features dual closets and vanities in the bath. A large Main Suite and spacious walk-in shower give a luxurious feel. The lower level also has a Guest Suite with private bath and a nice sized Utility Room and Powder Bath. The second floor contains three additional Guest Suites, one could function as a second main suite with a private bath, two closets, and large balcony looking out to the view. There is also a morning kitchen for early morning coffees or late night drinks as well as a large hall storage closet.

Full Specs & Features


Dimension

Depth : 107' 4"

Height : 32' 8"

Width : 44' 8"

Area

Decks : 351 sq/ft

Garage : 803 sq/ft

Main Floor : 2522 sq/ft

Porch : 497 sq/ft

Upper Floor : 1360 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Ceiling heights range from 10 ft. to 12 ft.

Garage Ceiling : 10'

Main Ceiling : 10' 8"

Upper Ceiling Ft : 10'

Roof

Primary Pitch : 5/12

Roof Type : Metal

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features

2 Master Suites

Guest Suite

Main Floor Bedrooms

Main Floor Master Bedroom

Upstairs Bedrooms

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Storage Area

Wet Bar

Garage Features

Front Entry Garage

Side Entry Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Balcony

Covered Rear Porch

Outdoor Kitchen Grill

More

Additional Half Bath

What's Included In This Plan Set


This designer charges $75.00 to review plan changes and prepare an estimate for your modifications. This fee can be applied to your plan purchase once you move forward with the modifications. Please give us a call if you would like to order a Plan Modification quote.

Some of this designer's ready-made house plans are not for sale in Lee and Collier, and Charlotte Counties of Florida. Please give us a call if you are building in one of these counties.

Cover Sheet, Index & Site Plan: The cover sheet features an elevation of the exterior of the house that shows approximately how the home will look when built. The index lists the order of the drawings included, with page numbers for easy reference. The site plan is a scaled footprint of the house to help determine how the home will be placed on the building site.

Wall Sections & Notes: This section shows section cuts of the exterior wall from the roof down through the foundation. These wall sections specify the home’s construction and building materials. They also show the number of stories, type of foundation and the construction of the walls. Roofing materials, insulation, floor framing, wall finishes and elevation heights are all shown and referenced.

Typical Details & Notes: This section addresses all the facets and typical details you will want to include in your home, with the exception of local building code requirements. Architectural and structural elements are detailed, including: window and door components, railings, balusters, wood stairs and headers, interior walls, interior partitions, concrete steps and footings (if applicable).

Foundation layout Plan: This sheet provides a fully dimensioned and noted foundation layout, including references to footings, pads, and support walls. For plans with a basement, additional walls and columns may be shown. Basement plans come with a floor framing layout which may be included in this section or the floor framing section, depending on the plan. *Actual structural information should be obtained by a locally licensed engineer for your specific site location.

Detailed Floor Plan: This section provides detailed floor plan drawings and descriptions of all the elements that will be included on each floor of the home. The home’s exterior footprint, openings and interior rooms are carefully dimensioned. Important features are noted including built-ins, niches and appliances. All doors and windows are identified. Typically this section also includes the square footage information.

Reflected Ceiling Plan: This designer's most distinguishable features is the highly detailed ceiling treatments. This section shows ceiling heights and treatments. It also shows the details, profiles and finishes of the ceiling treatments. Arches and soffits are also specified in this section.

Floor Framing Plans: Homes with a basement or crawl space will have a floor framing plan for the first floor. Multi-story homes will have floor framing plans for upper floors as well. The floor framing plans provide structural information such as the joist location, spacing and direction, as well as the floor heights and stair openings.

Roof Layout: The overall layout and necessary details for roof design are provided in this section. If trusses are used, we suggest using a local truss manufacturer to design your roof trusses to comply with your local codes and regulations.

Exterior Elevations: Exterior elevations are drawings that show how the finished home will approximately look. In this section, elevations of the front, rear and left and right sides of the home are shown. Exterior materials, details and heights are noted on these drawings.

Building Section & Details: This section will illustrate the important changes in the floor, ceiling and roof heights or the relationship of different floors to one another. Interior elements of rooms and areas, such as columns, arches, headers and soffits, are also discernible and easier to visualize in a cross section.

Interior Elevations: These interior elevations show the specific details and design of the kitchen, bathrooms, utility rooms, fireplaces, bookcases, built-in units and other special interior features. The interior elevations vary based on the complexity of the home.

Electrical Plan: This section shows an electrical plan that will enhance functionality and highlight the unique architectural features of the home.
