PLAN 929-931
Key Specs
3899
sq ft
3
Beds
3.5
Baths
1
Floors
3
Garages
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 929-931
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Graceful arches accent the windows and entry porch of this spacious hillside walkout home. A mixture of stone and wood shake siding adds craftsman flair to the design. Inside, the formal dining room and bedroom/study flank each side of the foyer. The great room lies straight ahead and makes the most of rear views through a two-story wall of windows. A powder bath is tucked away in the service area off the kitchen, along with a pantry. Highlights of the luxurious master suite include the sitting area in a bow window and the spacious bathroom.
Full Specs & Features
Height : 40' 3"
Width : 82' 4"
Basement Unfinished: 1232 sq/ft
First Floor: 2515 sq/ft height 10'
Garage: 1006 sq/ft
Patio: 314 sq/ft
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 5:12
Framing : Wood - 2x6
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Island
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Mud Room
Open Floor Plan
Storage Area
Sunroom
Vaulted / Cathedral Ceilings
Covered Front Porch
Covered Rear Porch
Outdoor Fireplace
Screened Porch
Bedroom 2:
width 12' x depth 21' 6"
Bedroom 3:
width 13' 8" x depth 14'
Breakfast:
width 10' x depth 13'
Dining:
width 15' x depth 12'
Foyer:
width 7' x depth 12'
Great Room:
width 22' x depth 20'
Kitchen:
width 14' x depth 14' 8"
Master Bedroom:
width 18' x depth 15'
Patio:
314 sq/ft width 30' x depth 10'
Porch Front:
58 sq/ft width 10' x depth 5' 8"
Porch Rear:
301 sq/ft width 30' x depth 10'
Porch Screened:
210 sq/ft width 14' x depth 15'
Recreation Room:
width 23' 6" x depth 20'
Study:
width 13' x depth 14'
Utility Room:
width 8' x depth 8' 8"
What's Included In This Plan Set
Donald A. Gardner typically charges $100.00 to review plan changes and prepare an estimate for your modifications.
However, for a limited time, we're cutting that in half to only $49.00! This fee can be applied to your plan modifications once you move forward with the service. Please call if you would like to order a Plan Modification quote from the Donald A. Gardner Plan Collection.
Purchasing a CAD set gives you an unlimited build license. All other plan sets, excluding the Single Set for bidding purposes, allow you to build the home one time.
- Cover Sheet - A rendering of the front exterior of the house.
- Foundation Plan - This plan gives the foundation layout, including support walls, excavated and unexcavated areas, if any, foundation notes and details, and floor framing.
- Detailed Floor Plans - These plans show the layout of each floor of the house. Rooms and interior spaces are carefully dimensioned and keys are given for cross-section details provided later in the plans, as well as window and door schedules. These plans may also show the location of kitchen appliances and plumbing fixtures, and may suggest locations for electrical fixtures, switches and outlets.
- Interior Elevations - The interior elevation drawings show a suggested layout design of cabinets, utility rooms, fireplaces, bookcases, built-in units and other special interior features depending on the nature and complexity of the item.
- Roof Plan - The roof plan shows a bird's eye view of the overall layout of the roof, ridges, valleys, and slopes.
- Door and window schedules - Sizes, quantities and descriptions of all doors and windows shown on the plan.
- Exterior Elevations - Included are front, rear, left and right sides of the house. Exterior materials, details and measurements are also given.
- Cross-Section / Wall Section Details - Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Also shown, when applicable, are exterior details such as railing and banding.
- Structural Plan - Overall layout and necessary details for the ceiling, second-floor framing (if applicable) and roof construction. If trusses are used, it's suggested that you use a local truss manufacturer to design your trusses to comply with your local codes and regulations.
- Each plan is designed to be consistent with CABO One and Two Family Dwelling Code or the International Residential Code in effect at the time the plan was created. Modifications may be necessary to meet applicable building codes, ordinances, local climatic, and geographical design criteria. Consult a builder, architect or other construction professional as necessary. Manufacturer instructions should be followed for all materials, appliances, and systems. Heating/air conditioning layouts, plumbing pipe layouts, and electrical wiring layouts are not included. Consult a local mechanical contractor for systems suitable for local climate conditions.
| 5 Copy Set
: $2395.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set
: $2515.00 |
8 printed plan sets mailed to you. |
| PDF Set
: $3130.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set
: $3130.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set
: $6175.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
| Single Set
: $2205.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Walk Out Basement: $0.00 |
Ideal for a sloping lot, lower level with outdoor access. |
Framing
| Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
| Additional Construction Sets
: $125.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
