Bathroom 2:
44 sq/ft width 8' x depth 5' 6"
Bathroom 3:
44 sq/ft width 5' 3" x depth 8' 6"
Bathroom 4:
47 sq/ft width 9' x depth 5' 3"
Bedroom 2:
247 sq/ft width 16' 6" x depth 15'
Bedroom 2 Closet:
30 sq/ft width 5' 6" x depth 5' 6"
Bedroom 3:
228 sq/ft width 16' x depth 14' 3"
Bedroom 3 Closet:
30 sq/ft width 6' 6" x depth 4' 9"
Bedroom 4:
217 sq/ft width 15' x depth 14' 6"
Bedroom 4 Closet:
20 sq/ft width 4' x depth 5'
Breakfast Room:
180 sq/ft width 15' x depth 12'
Coat Closet:
18 sq/ft width 3' x depth 6'
Dining Room:
224 sq/ft width 13' x depth 17' 3"
Family Room:
486 sq/ft width 18' x depth 27'
Foyer:
127 sq/ft width 7' x depth 18' 3"
Kitchen:
280 sq/ft width 14' x depth 20'
Laundry Room:
82 sq/ft width 8' x depth 10' 3"
Master Bathroom:
167 sq/ft width 11' x depth 15' 3"
Master Bedroom:
280 sq/ft width 14' x depth 20'
Master Closet:
99 sq/ft width 11' x depth 9'
Study:
224 sq/ft width 14' x depth 16'
Sun Room:
184 sq/ft width 14' 6" x depth 12' 9"
All plans are drawn at ¼” scale or larger and include :
5 Copy Set : $1900.00 |
5 printed plan sets mailed to you. |
8 Copy Set : $2000.00 |
8 printed plan sets mailed to you. |
Reproducible Set : $2500.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
Single Set : $1500.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Basement: $0.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Right-Reading Reverse : $300.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
Additional Construction Sets : $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Mirror Reversed Sets : $80.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
