Bedroom 2:
176 sq/ft width 14' 8" x depth 12'
Bedroom 3:
240 sq/ft width 16' x depth 15'
Bedroom 4:
179 sq/ft width 13' 10" x depth 13'
Bonus Room - Finished:
425 sq/ft width 12' 6" x depth 34'
Dining Room:
197 sq/ft width 13' 2" x depth 15'
Family Room:
305 sq/ft width 16' 6" x depth 18' 6"
Foyer:
216 sq/ft width 13' x depth 16' 8"
Gathering Room:
375 sq/ft width 21' 8" x depth 17' 4"
Kitchen:
351 sq/ft width 20' 8" x depth 17'
Laundry Room:
75 sq/ft width 7' 4" x depth 10' 4"
Master Bathroom:
177 sq/ft width 12' 8" x depth 14'
Master Bathroom:
84 sq/ft width 7' x depth 12'
Master Bedroom:
319 sq/ft width 14' 6" x depth 22'
Master Closet - Hers:
84 sq/ft width 7' 6" x depth 11' 4"
Master Closet - His:
53 sq/ft width 7' 6" x depth 7' 2"
Office:
64 sq/ft width 8' x depth 8'
Pantry:
39 sq/ft width 7' 4" x depth 5' 4"
Porch - Front:
91 sq/ft width 14' x depth 6' 6"
Porch - Screened:
145 sq/ft width 14' 4" x depth 10' 2"
Sitting Area:
90 sq/ft width 11' 4" x depth 8'
Study:
237 sq/ft width 15' x depth 15' 10"
Terrace:
504 sq/ft width 36' x depth 14'
PDF Set
: $1950.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Reproducible Set
: $1950.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Additional Construction Sets
: $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design
: $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Mirror Reversed Sets
: $0.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
