Key Specs

5160
sq ft

5
Beds

5
Baths

2
Floors

2
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

This beautiful rambler has a self-contained apartment in the basement with a separate entrance that is perfect for an in-law apartment or extra income. Gorgeous picture windows and a fireplace give the main living area of the home a cozy feel with plenty of natural light. Large bedrooms provide plenty of private space. The home owner’s side of the basement has a kitchenette of it's own along with a dining and family area that could be a media room or game room. Upstairs, there is a bonus room with a bathroom of it's own and large windows along the walls.

Floor Plans

Floor Plan - Main Floor Plan

Floor Plan - Upper Floor Plan

Floor Plan - Lower Floor Plan

Floor Plan - Other Floor Plan

Full Specs & Features

Dimension

Depth : 39'
Height : 22' 10"
Width : 66'

Area

Basement Living: 2240 sq/ft height 8'
First Floor: 2126 sq/ft
Garage: 481 sq/ft
Second Floor: 794 sq/ft height 8'

Roof

Roof Framing : Conventional
Primary Pitch : 8:12
Secondary Pitch : 4:12
Roof Type : Asphalt

Exterior Wall Framing

Exterior Wall Finish : Brick/Stucco

Bedroom Features

Guest Suite
Main Floor Master Bedroom
Walk In Closet
Fireplace

Kitchen Features

Kitchen Island

Additional Room Features

Family Room Keeping Room
Great Room Living Room
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings

Garage Features

Front Entry Garage

Outdoor Spaces

Covered Front Porch

Rooms

Basement Bath 1:

72 sq/ft width 14' 5" x depth 5'

Basement Bedroom 1:

126 sq/ft width 11' x depth 11' 5"

Basement Bedroom 2:

165 sq/ft width 11' x depth 15'

Basement Closet 1:

34 sq/ft width 5' 10" x depth 5' 9"

Basement Closet 2:

34 sq/ft width 5' 10" x depth 5' 9"

Basement Dining:

216 sq/ft width 17' 3" x depth 12' 6"

Basement Family Room 1:

370 sq/ft width 28' 3" x depth 13' 1"

Basement Family Room 2:

191 sq/ft width 21' 1" x depth 9' 1"

Basement Kitchen 1:

196 sq/ft width 18' 8" x depth 10' 6"

Basement Kitchen 2:

129 sq/ft width 11' 1" x depth 11' 8"

Bath 2:

99 sq/ft width 6' x depth 16' 7"

Bath 3:

45 sq/ft width 9' x depth 5'

Bedroom 1:

133 sq/ft width 11' 1" x depth 12'

Bedroom 2:

135 sq/ft width 11' 1" x depth 12' 2"

Covered Front Porch:

65 sq/ft

Dining Area:

201 sq/ft width 19' 5" x depth 10' 4"

Entry:

120 sq/ft width 9' x depth 13' 4"

Finished Bonus Room:

794 sq/ft width 45' 3" x depth 16' 3"

Garage:

481 sq/ft width 21' 7" x depth 22'

Great Room:

322 sq/ft width 19' 5" x depth 16' 7"

Kitchen:

191 sq/ft width 13' 10" x depth 13' 10"

Laundry Room:

130 sq/ft width 10' x depth 13'

Master Bath:

93 sq/ft width 9' 6" x depth 9' 9"

Master Bedroom:

210 sq/ft width 13' 1" x depth 16' 1"

Master Closet:

40 sq/ft width 9' 6" x depth 6' 1"

Mechanical:

36 sq/ft width 6' 6" x depth 5' 6"

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

» See important information before purchasing.

Plan Set

5 Copy Set : $950.00	5 printed plan sets mailed to you.
8 Copy Set : $1000.00	8 printed plan sets mailed to you.
PDF Set : $1200.00	PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set : $1250.00	For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set : $1750.00	For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set : $825.00	One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Daylight Basement: $0.00	Ideal for sloping lot, lower level of home partially underground.
Crawlspace: $250.00	Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab: $250.00	Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x4:
$50.00

Wood 2x4

Additional Options

Additional Construction Sets : 25.00	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design : 100.00	Receive an overlay sheet with suggested placement of audio and video components.
Home Furniture Planner : 19.00	This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.
Lighting Design : 200.00	Receive an overlay sheet with suggested placement of lighting fixtures.
Right-Reading Reverse : 250.00	Choose this option to reverse your plans and to have the text and dimensions readable.
