Bedroom 2:
182 sq/ft width 13' x depth 14'
Bedroom 3:
268 sq/ft width 14' 6" x depth 18' 6"
Bedroom 4:
210 sq/ft width 15' x depth 14'
Bedroom 5:
171 sq/ft width 12' 8" x depth 13' 6"
Breakfast Room:
182 sq/ft width 13' 6" x depth 13' 6"
Dining Room:
247 sq/ft width 13' 6" x depth 18' 4"
Foyer:
196 sq/ft width 14' x depth 14'
Game Room:
500 sq/ft width 19' x depth 26' 4"
Garage:
523 sq/ft width 21' 6" x depth 24' 4"
Garage Storage:
1400 sq/ft width 35' x depth 40'
Gathering Room:
564 sq/ft width 24' x depth 23' 6"
Kitchen:
406 sq/ft width 19' x depth 21' 5"
Master Bathroom:
258 sq/ft width 12' x depth 21' 6"
Master Bedroom:
335 sq/ft width 19' x depth 17' 8"
Storage:
47 sq/ft width 5' x depth 9' 6"
Study:
195 sq/ft width 14' 8" x depth 13' 4"
Utility Room:
80 sq/ft width 7' 6" x depth 10' 8"
All plans are drawn at ¼” scale or larger and include :
PDF Set : $1815.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Wood 2x4: $0.00 |
Wood 2x4 |
Additional Construction Sets : $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Material List : $85.00 |
A list of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options. |
Mirror Reversed Sets : $55.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
