239 sq/ft width 14' 2" x depth 16' 11"
166 sq/ft width 11' 11" x depth 14'
922 sq/ft width 25' 4" x depth 36' 5"
291 sq/ft width 16' 8" x depth 17' 6"
429 sq/ft width 25' 5" x depth 16' 11"
56 sq/ft width 10' 8" x depth 5' 3"
279 sq/ft width 16' 11" x depth 16' 6"
88 sq/ft width 8' 7" x depth 10' 4"
This designer charges a non-refundable $95.00 fee to review plan changes and prepare an estimate for your modifications. Please call if you would like to order a Plan Modification quote for this plan. All plans are drawn at ¼” scale or larger and include : Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas. Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches. Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing. Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required. » See important information before purchasing.
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|Ideal for sloping lot, lower level of home partially underground.|
|Choose this option to reverse your plans and to have the text and dimensions readable.|
|Audio Video Design
|Receive an overlay sheet with suggested placement of audio and video components.|
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Receive an overlay sheet with suggested placement of lighting fixtures.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
