PLAN 132-477

Key Specs

5680
sq ft

5
Beds

4.5
Baths

3
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

Beautifully detailed rooms radiate from the octagonal rotunda at the center of this plan. Stairs wrap around its perimeter, leading down to the basement and up to the private rooms on the second level, which include a sunny loft and a large flex room, as well as three bedrooms and two baths. The master suite is also on the second level and features a fireplace and a well-planned luxury bath. Note conveniences like the large utility room off the garage and the walk-in pantry in the kitchen. Architectural touches such as columns, niches, and a variety of ceiling treatments add class.

Floor Plans

Floor Plan - Lower Floor Plan

Reverse

Victorian Floor Plan - Lower Floor Plan Plan #132-477

Floor Plan - Main Floor Plan

Reverse

Victorian Floor Plan - Main Floor Plan Plan #132-477

Floor Plan - Upper Floor Plan

Reverse

Victorian Floor Plan - Upper Floor Plan Plan #132-477

Full Specs & Features

Dimension

Depth : 60'
Height : 38' 9"
Width : 67'

Area

Basement Living: 1595 sq/ft
First Floor: 2025 sq/ft
Garage: 900 sq/ft
Porch: 395 sq/ft
Second Floor: 2060 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Shingle/Stone
Framing : Wood - 2x6

Bedroom Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Media Room
Storage Area
Unfinished Future Space
Vaulted / Cathedral Ceilings

Outdoor Spaces

Balcony
Courtyard
Covered Front Porch
Covered Rear Porch
Deck

What's Included In This Plan Set

See a sample plan set

Purchasing a CAD set gives you a multi-build license. The 5 copy set allows you to build the home one time.

If you are building this plan in the state of Washington, please call us before placing your order.

Cover Sheet: The cover sheet includes the general notes and building code information, design standards and structural materials specifications required to construct your home.
Schedule Sheet: The schedule sheet includes the window, roof and foundation ventilation schedules, insulation and vapor barrier specifications, and exhaust fan ventilation schedule.
Detail Sheet: The detail sheet shows building components at large scale as required to explain construction of footings, foundation walls, concrete slabs, framed floors and walls, posts, beams, insulation, eaves, roofs, vents, stairs, skylights, and connections.
Foundation Plan Sheet: The foundation plan sheet shows the layout of the crawl space, walk-out basement or slab foundation. The foundation plan includes all necessary notes, dimensions, concrete walls, footing pads, posts, beams, bearing walls, crawlspace vents, footing schedule, steel reinforcing, and structural information. If you require a different foundation type, please contact us for modifications to your plan.
Floor Plan Sheet: Floor plans are horizontal cuts through each floor level of the home, usually at 5' above the floor. The floor plan shows the location of interior and exterior walls, doors, windows, stairs, closets, cabinets, flooring, appliances, plumbing fixtures, fireplaces, posts and beams. Floor plans also indicate vaulted, coffered, or box beam ceilings, cased openings and areas with ceiling soffits.
Roof Framing Plan Sheet: The roof framing plan shows the geometry of the hips, ridges, valleys, dormers, roof pitches, wall and plate heights, and overhangs. The plan also shows all individual roof framing members, trusses, rafters, beams, skylights, roof vents, gutters, downspouts, skylights, bearing walls under framing members, and point loads.
Elevation Sheet: Exterior elevations show all four sides of the house, describing the roofing, siding, and trim materials, doors, windows, roof pitches, skylights, gutters, chimneys, wall heights, finish grade and overall building height.
Building Section Sheet: Building sections are vertical cuts through the house from the roof to the foundation. The sections illustrate the construction sequence from bottom to top starting with excavation, proceeding up through the foundation, drainage, wall and floor framing, stair framing, roof framing, windows, doors, venting, and exterior and interior finishes. Wall plate heights for each floor are also delineated.
