PLAN 48-433

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


This ranch design floor plan is 5884 sq ft and has 5 bedrooms and 5.5 bathrooms.

Full Specs & Features


Dimension

Depth : 115' 8"

Height : 17'

Width : 165'

Area

First Floor: 5884 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 4:12

Roof Framing : stick

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding

Framing : 2"x6"

Bedroom Features

Guest Suite

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Breakfast Nook

Butler's Pantry

Eating Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Hobby Rec Room Game Room

Play Flex Room

Storage Area

Garage Features

Oversized Garage

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Outdoor Spaces

Breezeway

More

Jack & Jill Bath

Rooms

Bathroom 2:

51 sq/ft width 6' x depth 8' 6"

Bathroom 3:

104 sq/ft width 13' x depth 8'

Bathroom 4:

105 sq/ft width 7' 6" x depth 14'

Bathroom 5:

45 sq/ft width 9' x depth 5'

Bedroom 2:

156 sq/ft width 12' x depth 13'

Bedroom 2 Closet:

12 sq/ft width 6' x depth 2'

Bedroom 3:

155 sq/ft width 13' 4" x depth 11' 8"

Bedroom 3 Closet:

12 sq/ft width 6' x depth 2'

Bedroom 4:

156 sq/ft width 14' x depth 11' 2"

Bedroom 4 Closet:

30 sq/ft width 5' x depth 6'

Bedroom 5:

165 sq/ft width 14' x depth 11' 10"

Bedroom 5 Closet:

18 sq/ft width 9' x depth 2'

Butler's Pantry:

30 sq/ft width 6' x depth 5'

Dining Room:

210 sq/ft width 18' x depth 11' 8"

Exercise Room:

256 sq/ft width 16' x depth 16'

Family Room:

391 sq/ft width 17' x depth 23'

Foyer:

180 sq/ft width 18' x depth 10'

Game Room:

240 sq/ft width 16' x depth 15'

Garage:

850 sq/ft width 34' x depth 25'

Hall:

330 sq/ft width 55' x depth 6'

Hall Bathroom:

42 sq/ft width 6' x depth 7'

Hall Closet:

10 sq/ft width 5' x depth 2'

Kitchen:

312 sq/ft width 24' x depth 13'

Kitchen Island:

52 sq/ft width 13' x depth 4'

Linen Closet:

26 sq/ft width 13' x depth 2'

Living Room:

418 sq/ft width 19' x depth 22'

Master Bathroom:

282 sq/ft width 18' x depth 15' 8"

Master Bedroom:

282 sq/ft width 18' x depth 15' 8"

Master Closet:

234 sq/ft width 26' x depth 9'

Mud Room:

121 sq/ft width 11' x depth 11'

Office:

180 sq/ft width 15' x depth 12'

Pantry:

49 sq/ft width 7' x depth 7'

Porch - Rear:

84 sq/ft width 21' x depth 4'

Toilet Closet:

17 sq/ft width 3' 5" x depth 5'
