PLAN #17-3316

Key Specs

sq ft





This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans

Floor Plan - Main Floor Plan
Traditional Floor Plan - Main Floor Plan Plan #17-3316
Floor Plan - Upper Floor Plan
Traditional Floor Plan - Upper Floor Plan Plan #17-3316

Full Specs & Features

Dimension Depth : 79' 2"
Height : 31'
Width : 69' 10"
Area Bonus : 360 sq/ft
Garage : 752 sq/ft
Lower Floor : 2922 sq/ft
Main Floor : 2712 sq/ft
Porch : 1133 sq/ft
Upper Floor : 455 sq/ft
Bedroom Features Guest Suite
Main Floor Master Bedroom
Formal Dining Room
Kitchen Features Kitchen Island
Kitchenette Wet Bar
Breakfast Nook
Additional Room Features Family Room Keeping Room
Great Room Living Room
Master Sitting Area
Media Room
Unfinished Future Space
Outdoor Spaces Covered Front Porch
Covered Rear Porch
Bedroom 3 123 sq/ft width 11' 4" x depth 10' 11"
Bedroom 4 120 sq/ft width 11' 4" x depth 10' 8"
Bonus Room - Unfinished 342 sq/ft width 11' 8" x depth 29' 4"
Breakfast Room 99 sq/ft width 11' x depth 9'
Covered Porch 410 sq/ft width 22' 10" x depth 18'
Dining Room 168 sq/ft width 12' x depth 14'
Foyer 117 sq/ft width 9' 5" x depth 12' 6"
Garage 732 sq/ft width 21' 4" x depth 34' 4"
Great Room 426 sq/ft width 21' 6" x depth 19' 10"
Grilling Porch 410 sq/ft width 22' 10" x depth 18'
Guest Bedroom 168 sq/ft width 14' x depth 12'
Hearth Room 154 sq/ft width 11' x depth 14'
Kitchen 154 sq/ft width 10' 4" x depth 15'
Master Sitting Room 87 sq/ft width 9' 4" x depth 9' 4"
Master Suite 205 sq/ft width 13' 6" x depth 15' 3"
Media Room 218 sq/ft width 16' x depth 13' 8"

What's Included In This Plan Set

  • Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
  • Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
  • Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
  • Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
  • Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
  • Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
  • Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
» See important information before purchasing.
Plan Set
5 Copy Set :
5 printed plan sets mailed to you.
8 Copy Set :
8 printed plan sets mailed to you.
PDF Set :
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set :
For making minor changes to your house plans and inexpensive local printing. 1 printed set on Vellum or Bond paper.
CAD Set :
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set :
One printed set for bidding purposes only. Not a legal building set for construction.
Daylight Basement:
Ideal for sloping lot, lower level of home partially underground.
Wood 2x4:
Wood 2x4
Additional Options
Right-Reading Reverse :
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Home Furniture Planner :
This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.
Lighting Design :
Receive an overlay sheet with suggested placement of lighting fixtures.
Audio Video Design :
Receive an overlay sheet with suggested placement of audio and video components.
