This inspiring design features the perfect master suite. Designed for elegance, convenience and privacy, it is certain to delight and comfort the homeowners day after day. With 344 square feet of floor space under a 10-foot, octagonal tray ceiling, it will easily accomodate a grand old bed and several bureaus without feeling cramped. A window-lined bay with access to the terrace can hold a couple of comfortable chairs. The master bath provides each spouse with his or her own private space, approached through two separate dressing areas with adjoining walk-in closets. Each bath includes a sink, vanity, linen closet, and toilet. They are linked by a bayed space containing a huge soaking tub and a shower. Look closely at the floor plan to see that this home contains all the other conveniences and everyday luxuries demanded by today's homeowners.
Bedroom 2:
187 sq/ft width 15' x depth 12' 6"
Bedroom 3:
367 sq/ft width 18' 10" x depth 19' 6"
Bedroom 4:
288 sq/ft width 18' x depth 16'
Bedroom 5:
297 sq/ft width 17' x depth 17' 6"
Bonus Room - Unfinished:
549 sq/ft width 30' 6" x depth 18'
Breakfast Room:
104 sq/ft width 11' x depth 9' 6"
Dining Room:
247 sq/ft width 15' x depth 16' 6"
Garage:
540 sq/ft width 23' x depth 23' 6"
Garage Two:
632 sq/ft width 27' 6" x depth 23'
Gathering Room:
297 sq/ft width 17' x depth 17' 6"
Grand Room:
408 sq/ft width 24' x depth 17'
Kitchen:
378 sq/ft width 21' x depth 18'
Master Bedroom:
344 sq/ft width 16' x depth 21' 6"
Study:
280 sq/ft width 17' x depth 16' 6"
Theatre Room:
481 sq/ft width 20' 6" x depth 23' 6"
PDF Set
: $2400.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Reproducible Set
: $2400.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Wood 2x4: $0.00 |
Wood 2x4 |
Right-Reading Reverse
: $200.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
Additional Construction Sets
: $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design
: $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Mirror Reversed Sets
: $50.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
