PLAN 1105-1
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 38'
Height : 14'
Width : 24'
Area
Main Floor : 720 sq/ft
Porch : 48 sq/ft
Ceiling
Ceiling Details : Single pitch interior vault
Lower Ceiling : 7' 10"
Upper Ceiling Ft : 11' 8"
Roof
Primary Pitch : 2:12
Roof Framing : 2x12@24" oc
Roof Load : 25psf snow
Roof Type : Rafters
Exterior Wall Framing
Exterior Wall Finish : Lap/vertical wood
Framing : 2x6@16" oc
Insulation : 1" cont. ext. rigid foam, blown-in in walls
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Kitchen Features
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Lot Characteristics
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Economical To Build
Empty Nester
Suited For Vacation Home
Energy Efficient Features
Energy Efficient Design
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$796.00
$1356.00
$1596.00
Foundation
$0.00
$316.00
Framing
$0.00
Additional Options
$236.00
$132.00
$236.00
$31.20
$132.00
$120.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
