Plan Description

This petite Carpenter Gothic charmer would make an ideal vacation or starter home. The exterior boasts a heavy wood-shingled roof, board-and-batten siding and scroll-sawn detailing. A well-planned interior is simplicity itself: a double-door entry leads to an open living, dining and kitchen area. The kitchen is hidden from the living room by a stairway and a half-bath. Nine-foot ceilings highlight the second floor, which contains two bedrooms--each with plenty of closet space--and a paneled bathroom.

Floor Plans

Floor Plan - Main Floor

Reverse

Dream House Plan - Craftsman Floor Plan - Main Floor Plan #1016-1

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Dream House Plan - Craftsman Floor Plan - Upper Floor Plan #1016-1

Full Specs & Features

Dimension

Depth : 28'

Height : 27'

Width : 16'

Area

First Floor: 448 sq/ft

Second Floor: 448 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12

Roof Framing : Conventional

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x4

Bedroom Features

Formal Living Room / Parlor

Outdoor Spaces

Covered Front Porch

Rooms

Bathroom 2:

40 sq/ft width 5' x depth 8' 2"

Bedroom 2:

117 sq/ft width 13' x depth 9'

Hall Bathroom:

17 sq/ft width 3' x depth 5' 8"

Kitchen:

137 sq/ft width 15' 4" x depth 9'

Living Room:

173 sq/ft width 15' 4" x depth 11' 4"

Master Bedroom:

147 sq/ft width 13' x depth 11' 4"

Porch - Front:

width 0" x depth 5' 4"

Porch - Rear:

width 0" x depth 3' 6"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
