Plan Description


Grand is only the beginning! Extensive outdoor living space, particularly the cathedral-ceilinged loggia with summer kitchen, makes this the home everyone wants to come to.

Full Specs & Features


Dimension

Depth : 155' 6"

Height : 41' 1"

Width : 117' 4"

Area

Bonus: 665 sq/ft

First Floor: 5580 sq/ft height 12'

Garage: 1173 sq/ft

Porch: 3852 sq/ft

Second Floor: 3780 sq/ft height 10'

Storage: 1847 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 12'

Upper Ceiling Ft : 10'

Roof

Primary Pitch : 8:12

Roof Framing : Stick

Roof Type : Shake

Exterior Wall Framing

Exterior Wall Finish : Brick

Framing : Wood - 2x4

Bedroom Features

Guest Suite

Main Floor Master Bedroom

Split Bedrooms

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Exercise Room

Family Room Keeping Room

Great Room Living Room

Hobby Rec Room Game Room

Main Floor Laundry

Mud Room

Storage Area

Upstairs Laundry

Garage Features

Carport Porte Cochere

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Outdoor Kitchen Grill

Wrap Around Porch

Rooms

Bedroom 2:

462 sq/ft width 18' x depth 25' 8"

Bedroom 3:

310 sq/ft width 21' 5" x depth 14' 6"

Bedroom 4:

293 sq/ft width 19' 7" x depth 15'

Bedroom 5:

267 sq/ft width 19' 7" x depth 13' 8"

Bedroom 6:

184 sq/ft width 16' x depth 11' 6"

Billiards Room:

472 sq/ft width 21' x depth 22' 6"

Breakfast:

216 sq/ft width 13' 6" x depth 16'

Dining Room:

348 sq/ft width 16' x depth 21' 9"

Family Room:

472 sq/ft width 21' x depth 22' 6"

Fitness Room:

200 sq/ft width 14' x depth 14' 4"

Game Room:

434 sq/ft width 23' 6" x depth 18' 6"

Garage:

1103 sq/ft width 25' 8" x depth 43'

Kitchen:

358 sq/ft width 20' 6" x depth 17' 6"

Kitchen:

118 sq/ft width 9' 7" x depth 12' 4"

Library:

340 sq/ft width 21' 3" x depth 16'

Living Room:

352 sq/ft width 22' x depth 16'

Living Room:

208 sq/ft width 16' x depth 13'

Loggia:

454 sq/ft width 20' 6" x depth 22' 2"

Master Bathroom:

255 sq/ft width 15' 6" x depth 16' 6"

Master Bedroom:

441 sq/ft width 18' x depth 24' 6"

Master Closet:

108 sq/ft width 15' 6" x depth 7'

Master Closet Two:

181 sq/ft width 16' 6" x depth 11'

Porch - Front:

1186 sq/ft width 85' 9" x depth 13' 10"

Porch - Rear:

503 sq/ft width 53' x depth 9' 6"

Port Cochere:

332 sq/ft width 15' x depth 22' 2"

What's Included In This Plan Set


  • Cover Page: Front elevation and informative reference sections including: general notes and design criteria
  • Elevations: Drafted at 1/4" scale for the front and 1/8" scale for the rear and sides. All elevations are noted and an aerial view of the roof is provided, showing all hips, valleys and ridges.
  • Foundation: Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. Shows the HVAC equipment, structural information, steel beam and pole locations and the direction and spacing of the floor system above. Alternate foundations are available for a fee.
  • Main Level Floor Plan: 1/4" scale. Fully dimensioned from stud to stud for ease of framing. The detailed drawings include such things as structural header locations, framing layout and kitchen layout.
  • Second Level Floor Plan: 1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor plan.
  • Elevations: Useful for the cabinet and bidding process, this page shows all kitchen and bathroom cabinets as well as any other cabinet elevations.
  • Electrical and Sections: Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall and stair sections are provided to further explain construction of these areas.
