PLAN 314-215
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 33'
Height : 29'
Width : 39' 2"
Area
Basement Unfinished: 40 sq/ft
First Floor: 1029 sq/ft height 8'
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Kitchen Features
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Open Floor Plan
Unfinished Future Space
Upstairs Laundry
Workshop
Outdoor Spaces
Covered Front Porch
Deck
Rooms
Dining Room:
151 sq/ft width 11' 8" x depth 13'
Garage:
506 sq/ft width 22' x depth 23'
Gathering Room:
333 sq/ft width 25' 8" x depth 13'
Kitchen:
120 sq/ft width 12' x depth 10'
Master Bathroom:
48 sq/ft width 8' 10" x depth 5' 6"
Master Bedroom:
200 sq/ft width 12' 6" x depth 16'
Master Closet:
38 sq/ft width 5' 6" x depth 7'
Porch - Front:
164 sq/ft width 26' x depth 6' 4"
Utility Room:
12 sq/ft width 3' x depth 4' 2"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$696.00
$784.00
$844.00
$852.00
$1356.00
Foundation
$0.00
$0.00
$80.00
Framing
$0.00
$120.00
Additional Options
$280.00
$40.00
$80.00
$31.20
$76.00
$40.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
