Plan Description

Sleek and efficient, this modern three bedroom showcases a full wall of windows for maximum views and, if sited correctly, energy savings. Inside, the combination great room/dining space features an island kitchen. The master suite enjoys a private bath and walk-in closet, while on the opposite side, two family bedrooms share another full bath.

Floor Plans

Floor Plan - Main Floor Plan
Contemporary Floor Plan - Main Floor Plan Plan #569-27

Full Specs & Features

Depth : 24'
Height : 15' 8"
Width : 48'
First Floor: 1152 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 2:12
Roof Framing : Conventional
Roof Type : Composition
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Open Floor Plan
Vaulted / Cathedral Ceilings
Outdoor Spaces
Covered Rear Porch

2nd bath:

50 sq/ft width 5' 6" x depth 9'

Bedroom 1:

101 sq/ft width 11' 3" x depth 9'

Bedroom 2:

101 sq/ft width 11' 3" x depth 9'


816 sq/ft width 48' x depth 17'

Dining Room:

90 sq/ft width 11' 3" x depth 8'

Great Room:

159 sq/ft width 11' 7" x depth 13' 9"


90 sq/ft width 11' 3" x depth 8'

Master bath:

50 sq/ft width 5' 6" x depth 9'

Master Suite:

154 sq/ft width 11' 3" x depth 13' 9"

Master WIC:

50 sq/ft width 5' 6" x depth 9'

Porch - Rear:

159 sq/ft width 24' 6" x depth 6' 6"


36 sq/ft width 5' 6" x depth 6' 6"

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
