PLAN 47-863
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 32'
Height : 21'
Width : 52'
Area
Basement Unfinished: 858 sq/ft
First Floor: 1200 sq/ft height 8'
Roof
Primary Pitch : 7:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Formal Living Room / Parlor
Additional Room Features
Unfinished Future Space
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
11 sq/ft width 2' x depth 5' 8"
Bedroom 2:
102 sq/ft width 11' x depth 9' 4"
Bedroom 2 Closet:
11 sq/ft width 2' x depth 5' 8"
Bedroom 3:
93 sq/ft width 10' x depth 9' 4"
Bedroom 3 Closet:
11 sq/ft width 2' x depth 5' 8"
Deck:
164 sq/ft width 8' x depth 20' 6"
Dining Room:
115 sq/ft width 11' 6" x depth 10'
Foyer:
45 sq/ft width 6' 6" x depth 7'
Garage:
264 sq/ft width 23' x depth 11' 6"
Hall Bathroom:
54 sq/ft width 7' 4" x depth 7' 6"
Hall Closet:
23 sq/ft width 4' x depth 5' 10"
Kitchen:
95 sq/ft width 10' x depth 9' 6"
Living Room:
200 sq/ft width 16' x depth 12' 6"
Master Bathroom:
47 sq/ft width 6' 4" x depth 7' 6"
Master Bedroom:
154 sq/ft width 14' x depth 11'
