Full Specs & Features
Depth : 69'
Height : 21' 7"
Width : 28' 8"
First Floor: 1250 sq/ft height 9'
Lower Ceiling : 8'
Main Ceiling : 9'
Primary Pitch : 6:12
Roof Framing : Truss
Roof Load : 47 psf
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Siding, Stucco, Stone
Framing : 2"x6"
Insulation : Exterior R-19, Ceiling R-38
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Master Sitting Area
Rear Entry Garage
Suited For Corner Lot
Suited For Narrow Lot
Covered Front Porch
152 sq/ft width 12' x depth 12' 8"
155 sq/ft width 14' 4" x depth 10' 10"
380 sq/ft width 19' 4" x depth 19' 8"
64 sq/ft width 8' x depth 8'
195 sq/ft width 15' x depth 13'
100 sq/ft width 8' 6" x depth 11' 10"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
