PLAN 410-227
Key Specs
1270
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-800-447-0027
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Phone: 1-800-447-0027
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 410-227
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Dimension
Depth : 53'
Height : 17'
Width : 43'
Height : 17'
Width : 43'
Area
First Floor: 1270 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : 2"x4"
Framing : 2"x4"
Rooms
Bedroom 2:
113 sq/ft width 11' 4" x depth 10'
Bedroom 3:
126 sq/ft width 12' 8" x depth 10'
Dining Room:
126 sq/ft width 9' x depth 14'
Family Room:
264 sq/ft width 19' 4" x depth 13' 8"
Garage:
449 sq/ft width 19' x depth 23' 8"
Kitchen:
90 sq/ft width 9' x depth 10'
Master Bedroom:
168 sq/ft width 12' x depth 14'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
