PLAN #72-460

Key Specs


1410
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Mediterranean Floor Plan - Main Floor Plan Plan #72-460

Full Specs & Features


Dimension
Depth : 55'
Height : 20'
Width : 66' 7"
Area
First Floor: 1410 sq/ft height 8'
Roof
Primary Pitch : 7:12
Exterior Wall Framing
Framing : 2"x6"
Kitchen Features
Eating Bar
Additional Room Features
Storage Area
Outdoor Spaces
Covered Front Porch
Rooms

Bathroom 2:

88 sq/ft width 8' x depth 11' 1"

Dining Room:

132 sq/ft width 8' x depth 16' 6"

Hall Closet:

10 sq/ft width 2' 1" x depth 5'

Living Room:

214 sq/ft width 11' x depth 19' 6"

Master Bathroom:

82 sq/ft width 10' 4" x depth 8'

Porch - Front:

136 sq/ft width 23' 9" x depth 5' 9"

Porch - Rear:

78 sq/ft width 10' x depth 7' 10"

Utility Room:

43 sq/ft width 5' 5" x depth 8'

Walk-In Closet:

26 sq/ft width 4' 5" x depth 6'

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
