PLAN 456-86

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


This impressive design surely has down-home appeal. The most striking feature from the outside is the two-story tower, flanked on the rear by a pergola and to the front by an entrance deck and another pergola. Inside, a spiral stairway winds up one side of the tower to the second floor and higher to a lookout; then, it descends on the other side. A huge open space that can be used for both living and dining areas is warmed by a fireplace and separated from the kitchen by a snack bar. A wall of windows looks out over the front deck. A dreamy master suite opens to the rear deck and enjoys a huge whirlpool tub, a linen closet, and a walk-in closet. Two more bedrooms upstairs share a bath and a balcony overlooking the living area.

Full Specs & Features


Dimension

Depth : 38' 4"

Height : 32'

Width : 55' 4"

Area

First Floor: 1073 sq/ft height 8'

Second Floor: 697 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x6

Bedroom Features

Fireplace

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Loft

Main Floor Laundry

Garage Features

Detached Garage

Outdoor Spaces

Balcony

Deck

Rooms

3rd BR Closet:

10 sq/ft width 5' x depth 2'

Bathroom 2:

43 sq/ft width 5' x depth 8' 9"

Bedroom 2:

160 sq/ft width 13' x depth 12' 4"

Bedroom 2 Closet:

11 sq/ft width 5' 6" x depth 2'

Bedroom 3:

181 sq/ft width 16' x depth 11' 4"

Bedroom 3 Closet:

11 sq/ft width 5' 6" x depth 2'

Deck:

366 sq/ft width 36' 8" x depth 10'

Foyer:

90 sq/ft width 7' 7" x depth 12'

Garage:

400 sq/ft width 20' x depth 20'

Gathering Room:

333 sq/ft width 25' 8" x depth 13'

Hall Closet:

11 sq/ft width 5' 8" x depth 2'

Kitchen:

198 sq/ft width 17' x depth 11' 8"

Master Bathroom:

43 sq/ft width 5' x depth 8' 9"

Master Bedroom:

184 sq/ft width 15' x depth 12' 4"

Master Closet:

26 sq/ft width 5' x depth 5' 4"
