PLAN 1066-99
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 36'
Height : 20'
Width : 60'
Area
Bonus : 154 sq/ft
Main Floor : 1652 sq/ft
Porch : 55 sq/ft
Ceiling
Bonus Ceiling : 16' 6"
Ceiling Details : Garage area has two ceiling heights.
Main Ceiling : 11' 6"
Roof
Primary Pitch : 1/12
Roof Framing : Raftors
Roof Load : 25
Roof Type : Shed
Exterior Wall Framing
Exterior Wall Finish : Siding and Panels
Framing : 2X6
Insulation : R21
Garage Features
Front Entry Garage
Oversized Garage
Split Garage
More
Additional Half Bath
What's Included In This Plan Set
- Cover Sheet: 3D Rendering and Project Information.
- General Foundation notes (Builder and engineer to provide foundation specs based on lot and local code).
- Floor Plans (lower, main, upper, etc.) showing all doors and windows.
- Elevations from all four sides showing material callouts.
- Wall framing and sectional detail sheets.
- Building Cross Sections showing stair and ceiling height details.
- Window and Door schedule.
- Overhead roof plan showing peaks, valleys, and pitch.
- Foundation Plan showing perimeter and footing details.
- Wall and Roof framing details
- Misc. notes and details.
- *Please note that any structural engineering sheets included with this plan set are for reference only.
Plan Set
$602.00
