PLAN 406-9615
Key Specs
1874
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 406-9615
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 26'
Width : 64' 6"
First Floor: 1984 sq/ft
Garage: 500 sq/ft
Storage: 35 sq/ft
Main Ceiling : 10'
Roof Framing : 2x6 Framing
Roof Type : Shingle
Framing : 2"x4"
Main Floor Master Bedroom
Walk In Closet
Eating Bar
Kitchen Island
Storage Area
Suited For Narrow Lot
Covered Rear Porch
Bathroom 2:
46 sq/ft width 8' 5" x depth 5' 7"
Bedroom 2:
138 sq/ft width 12' x depth 11' 6"
Bedroom 2 Closet:
22 sq/ft width 11' 3" x depth 2'
Bedroom 3:
132 sq/ft width 12' x depth 11'
Bedroom 3 Closet:
12 sq/ft width 6' x depth 2'
Dining Room:
159 sq/ft width 12' x depth 13' 4"
Family Room:
247 sq/ft width 16' 6" x depth 15'
Garage:
451 sq/ft width 21' 3" x depth 21' 3"
Garage Storage:
21 sq/ft width 7' x depth 3'
Kitchen:
128 sq/ft width 8' 2" x depth 15' 9"
Kitchen Island:
14 sq/ft width 5' 10" x depth 2' 6"
Laundry Room:
30 sq/ft width 5' 2" x depth 5' 10"
Master Bathroom:
145 sq/ft width 10' 6" x depth 13' 10"
Master Bedroom:
226 sq/ft width 14' 4" x depth 15' 10"
Master Closet:
50 sq/ft width 7' 3" x depth 7'
Master Closet Two:
28 sq/ft width 4' 10" x depth 6'
Porch - Right:
78 sq/ft width 5' 10" x depth 13' 6"
What's Included In This Plan Set
- The first sheet is the cover sheet which outline the Design Criteria and Construction Notes, such as general site, foundation, framing and mechanical notes
- The second sheet is typically the front and side elevation drawn to 1/4" scale.
- The third sheet is the rear and side elevation drawn to 1/4" scale.
- The foundation of your choice (slab or crawlspace ). Floor Plan 1/4" Scale
- Detail and Section Page
- Cabinet elevations & Roof Plan
- Electrical Plan
- Foundation Details
| PDF Set : $1050.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $1115.00 |
5 printed plan sets mailed to you. |
| CAD Set : $1950.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Crawlspace: $350.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $255.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $255.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $55.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Material List : $65.00 |
A list of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
