Key Specs
1882
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 1010-7
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 48' 8"
Height : 32'
Width : 56' 4"
Area
Basement Unfinished: 1263 sq/ft
Bonus: 399 sq/ft
First Floor: 1412 sq/ft
Garage: 564 sq/ft
Porch: 95 sq/ft
Second Floor: 470 sq/ft
Roof
Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6
Bedroom Features
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Main Floor Laundry
Unfinished Future Space
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
135 sq/ft width 11' 4" x depth 12'
Bedroom 3:
120 sq/ft width 11' 8" x depth 10' 4"
Breakfast:
116 sq/ft width 11' 8" x depth 10'
Dining Room:
128 sq/ft width 11' 4" x depth 11' 4"
Garage:
566 sq/ft width 22' 8" x depth 25'
Great Room:
272 sq/ft width 15' x depth 18' 2"
Kitchen:
147 sq/ft width 11' 8" x depth 12' 8"
Master Bedroom:
210 sq/ft width 14' 4" x depth 14' 8"
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Plan: ?” scale; this shows roof rafter or trusses and how the roof is framed.
- CAD Plans are in AutoDesk Architecture.
Plan Set
$1300.00
$1350.00
$2600.00
$800.00
$800.00
Foundation
$0.00
Framing
$0.00
Additional Options
$75.00
$165.00
$295.00
$39.00
$165.00
$100.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
