PLAN 1016-13
Key Specs
1890
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 1016-13
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Full Specs & Features
Height : 23'
Width : 40'
Roof Framing : Conventional
Framing : Wood - 2x4
Formal Dining Room
3rd BR Closet:
10 sq/ft width 2' x depth 5'
Attic:
432 sq/ft width 12' x depth 36'
Basement Foundation:
693 sq/ft width 34' 8" x depth 20'
Bedroom 3:
113 sq/ft width 10' x depth 11' 4"
Bedroom 4:
127 sq/ft width 11' 3" x depth 11' 4"
Bedroom 4 Closet:
6 sq/ft width 2' x depth 3'
Breakfast Room:
82 sq/ft width 9' 6" x depth 8' 8"
Deck:
213 sq/ft width 8' x depth 26' 8"
Dining Room:
138 sq/ft width 12' 3" x depth 11' 4"
Foyer:
55 sq/ft width 8' 3" x depth 6' 8"
Hall:
width 4' 6" x depth 0"
Hall Bathroom:
46 sq/ft width 9' 4" x depth 5'
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
121 sq/ft width 11' x depth 11'
Laundry Room:
50 sq/ft width 7' 6" x depth 6' 8"
Living Room:
350 sq/ft width 16' 8" x depth 21'
Master Bathroom:
90 sq/ft width 10' x depth 9'
Master Bedroom:
235 sq/ft width 15' 4" x depth 15' 4"
Master Closet:
51 sq/ft width 10' 3" x depth 5'
Porch - Front:
32 sq/ft width 5' x depth 6' 7"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
