PLAN 406-246

Key Specs

sq ft





This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans

Floor Plan - Main Floor Plan
Traditional Floor Plan - Main Floor Plan Plan #406-246
Floor Plan - Other Floor Plan
Traditional Floor Plan - Other Floor Plan Plan #406-246

Full Specs & Features

Depth : 56'
Height : 23'
Width : 64'
Bonus: 400 sq/ft
First Floor: 1927 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Great Room Living Room
Storage Area
Unfinished Future Space
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Jack & Jill Bath

Bedroom 2:

140 sq/ft width 12' 6" x depth 11' 3"

Bedroom 3:

125 sq/ft width 12' x depth 10' 5"

Dining Room:

140 sq/ft width 10' 6" x depth 13' 5"


37 sq/ft width 5' x depth 7' 6"


465 sq/ft width 21' 8" x depth 21' 6"

Garage Storage:

37 sq/ft width 6' x depth 6' 2"


119 sq/ft width 8' 11" x depth 13' 5"

Laundry Room:

51 sq/ft width 5' 5" x depth 9' 6"

Living Room:

420 sq/ft width 19' 5" x depth 21' 8"

Master Bathroom:

104 sq/ft width 8' x depth 13' 1"

Master Bedroom:

235 sq/ft width 13' 4" x depth 17' 8"

Porch - Front:

168 sq/ft width 22' x depth 7' 8"

Porch - Rear:

180 sq/ft width 18' x depth 10'

What's Included In This Plan Set

  • The first sheet is the cover sheet which outline the Design Criteria and Construction Notes, such as general site, foundation, framing and mechanical notes
  • The second sheet is typically the front and side elevation drawn to 1/4" scale.
  • The third sheet is the rear and side elevation drawn to 1/4" scale.
  • The foundation of your choice (slab, crawl space or basement). Floor Plan 1/4" Scale
  • Detail and Section Page
  • Cabinet elevations & Roof Plan
  • Electrical Plan
  • Foundation Details
