Key Specs

sq ft





This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Plan Description

At just under 2,000 square feet, this rustic ranch features a carefully designed floor plan where every inch of space is incorporated into the living area that you'll use every day. As you enter, the formal dining room, with tray ceiling, lies to your right while the spacious great room, with corner fireplace and wall of windows, draws your attention directly ahead. The nook can double for a sunroom as it blends with the kitchen area to create a living space that's perfect for daily activities. The master suite lies to the left of the entry and includes step ceilings, a spacious walk-in closet and Jacuzzi tub. The second bedroom, which can also double as a den, lies behind the kitchen on the opposite side of the home for maximum privacy for mom and dad.

Floor Plans

Floor Plan - Main Floor Plan
Ranch Floor Plan - Main Floor Plan Plan #70-1039
Floor Plan - Upper Floor Plan
Ranch Floor Plan - Upper Floor Plan Plan #70-1039

Full Specs & Features

Depth : 65'
Height : 25' 9"
Width : 71'
First Floor: 1945 sq/ft
Garage: 921 sq/ft
Ceiling Details : Great Room, Foyer & Kitchen 11'Dining 12' TrayNook/Sunroom CathedralMaster Bedroom 10' Step
Main Ceiling : 9'
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47
Exterior Wall Framing
Exterior Wall Finish : Shake / Stone / Siding
Framing : 2 x 6
Insulation : R-19
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch

Basement Foundation:

4615 sq/ft width 71' x depth 65'

Bedroom 2:

146 sq/ft width 11' x depth 13' 4"

Bedroom 2 Closet:

11 sq/ft width 5' 8" x depth 2' 1"


266 sq/ft width 14' x depth 19'

Dining Room:

168 sq/ft width 12' x depth 14'


114 sq/ft width 8' x depth 14' 4"


559 sq/ft width 22' 8" x depth 24' 8"

Great Room:

266 sq/ft width 18' x depth 14' 10"

Half Bathroom:

30 sq/ft width 6' x depth 5'


182 sq/ft width 11' 8" x depth 15' 8"

Laundry Room:

67 sq/ft width 7' 6" x depth 9'

Master Bathroom:

156 sq/ft width 10' x depth 15' 8"

Master Bedroom:

221 sq/ft width 13' x depth 17'

Master Closet:

62 sq/ft width 6' 6" x depth 9' 8"


140 sq/ft width 11' 8" x depth 12'

Porch - Front:

414 sq/ft width 23' x depth 18'

What's Included In This Plan Set

  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
