Full Specs & Features
Depth : 50'
Height : 25'
Width : 42'
Bonus: 317 sq/ft
First Floor: 1032 sq/ft height 8'
Second Floor: 923 sq/ft
Primary Pitch : 7:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Formal Dining Room
Formal Living Room / Parlor
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Covered Front Porch
112 sq/ft width 10' 9" x depth 10' 6"
115 sq/ft width 10' 9" x depth 10' 9"
Bonus Room - Finished:
266 sq/ft width 19' x depth 14'
82 sq/ft width 9' 6" x depth 8' 8"
108 sq/ft width 12' x depth 9'
154 sq/ft width 11' x depth 14'
136 sq/ft width 13' x depth 10' 6"
186 sq/ft width 12' x depth 15' 6"
192 sq/ft width 12' x depth 16' 1"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
