PLAN 406-9616

Home > Style > Colonial House Plans

Key Specs

1990
sq ft

3
Beds

3.5
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

This colonial design floor plan is 1990 sq ft and has 3 bedrooms and 3.5 bathrooms.

Floor Plans

Floor Plan - Other Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Main Floor

Reverse

Full Specs & Features

Dimension

Depth : 51'

Height : 26'

Width : 64' 6"

Area

Bonus: 794 sq/ft

First Floor: 1990 sq/ft height 10'

Garage: 570 sq/ft

Porch: 449 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Main Floor ceiling heights are 9'-10'.

Main Ceiling : 9'

Upper Ceiling Ft : 8'

Roof

Primary Pitch : 10:12

Roof Framing : 2x8 Framing

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : brick veneer/siding

Framing : 2"x4"

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Play Flex Room

Storage Area

Unfinished Future Space

Lot Characteristics

Suited For Corner Lot

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Rooms

Bathroom 2:

37 sq/ft width 7' 5" x depth 5'

Bathroom 3:

37 sq/ft width 7' 5" x depth 5'

Bedroom 2:

132 sq/ft width 11' x depth 12'

Bedroom 3:

132 sq/ft width 11' x depth 12'

Bonus Room - Finished:

774 sq/ft width 43' x depth 18'

Breakfast:

100 sq/ft width 10' x depth 10'

Dining Room:

132 sq/ft width 12' x depth 11'

Family Room:

268 sq/ft width 14' 7" x depth 18' 5"

Garage:

518 sq/ft width 22' x depth 23' 7"

Kitchen:

132 sq/ft width 12' x depth 11'

Laundry Room:

41 sq/ft width 5' 4" x depth 7' 9"

Master Bathroom:

171 sq/ft width 9' 6" x depth 18'

Master Bedroom:

205 sq/ft width 14' x depth 14' 8"

Porch - Front:

192 sq/ft width 28' 6" x depth 6' 9"

Porch - Rear:

361 sq/ft width 28' 4" x depth 12' 9"

Study:

110 sq/ft width 10' x depth 11'
