PLAN 70-282
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Dimension
Depth : 51' 4"
Height : 24'
Width : 81'
Height : 24'
Width : 81'
Area
First Floor: 2003 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Entry / Dining Room: 10’ & Great Room and Bedroom #2: Cathedral
Main Ceiling : 8'
Main Ceiling : 8'
Roof
Primary Pitch : 9:12
Roof Framing : Truss
Roof Type : Shingle
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x6
Framing : Wood - 2x6
Bedroom Features
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Eating Bar
Additional Room Features
Great Room Living Room
Garage Features
Oversized Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Rooms
Bathroom 2:
36 sq/ft width 7' 4" x depth 5'
Bedroom 2:
143 sq/ft width 11' x depth 13'
Bedroom 3:
140 sq/ft width 11' 8" x depth 12'
Breakfast Room:
195 sq/ft width 14' 10" x depth 13' 2"
Dining Room:
136 sq/ft width 11' 8" x depth 11' 8"
Family Room:
192 sq/ft width 11' x depth 17' 6"
Garage:
893 sq/ft width 36' x depth 24' 10"
Hall Bathroom:
25 sq/ft width 4' 11" x depth 5' 3"
Kitchen:
190 sq/ft width 14' 6" x depth 13' 2"
Master Bathroom:
98 sq/ft width 7' 11" x depth 12' 6"
Master Bedroom:
192 sq/ft width 13' 4" x depth 14' 5"
Master Closet:
37 sq/ft width 10' x depth 3' 9"
Mud Room:
46 sq/ft width 8' 2" x depth 5' 8"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
