Key Specs
2028
sq ft
3
Beds
2.5
Baths
1
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBSUMMER
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-977
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 62'
Height : 25' 6"
Width : 66'
Area
First Floor: 2028 sq/ft height 8'
Ceiling
Lower Ceiling : 8'
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47 psf
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Siding, Stone
Framing : 2"x6"
Insulation : Exterior R-19, Ceiling R-38
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Great Room Living Room
Master Sitting Area
Storage Area
Garage Features
Oversized Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
122 sq/ft width 11' 6" x depth 10' 8"
Bedroom 3:
119 sq/ft width 11' x depth 10' 10"
Breakfast Nook:
161 sq/ft width 14' x depth 11' 6"
Dining Room:
114 sq/ft width 9' 10" x depth 11' 8"
Garage:
830 sq/ft width 35' 4" x depth 23' 6"
Great Room:
354 sq/ft width 19' 4" x depth 18' 4"
Kitchen:
186 sq/ft width 14' 2" x depth 13' 2"
Master Bedroom:
210 sq/ft width 14' 10" x depth 14' 2"
What's Included In This Plan Set
- Cover Sheet: Cover sheet with front rendering
- Foundation Plan(s): Foundation plans at 1/4" = 1' scale
- Floor Plan(s): Floor plans at 1/4" = 1' scale
- Exterior Elevations: Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Building sections and details as required to construct the individual design
- Electrical Plan(s): Schematic electrical plans with suggested switch, outlet, and light fixture locations
- Kitchen Cabinet Elevation(s): Interior elevation of cabinets at 1/4" = 1' scale
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Specification(s): General specification design notes
Plan Set
$925.65
$969.00
$1164.50
$1164.50
$1847.90
Foundation
$0.00
$335.75
$335.75
Additional Options
$335.75
$68.00
$140.25
$250.75
$33.15
$140.25
$63.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
