PLAN 406-140
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 81' 8"
Height : 23'
Width : 64' 2"
Area
Bonus: 1346 sq/ft
First Floor: 2062 sq/ft height 9'
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Great Room Living Room
Storage Area
Unfinished Future Space
Garage Features
Rear Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bathroom 2:
53 sq/ft width 10' 9" x depth 5'
Bedroom 2:
136 sq/ft width 11' 7" x depth 11' 9"
Bedroom 3:
140 sq/ft width 11' 11" x depth 11' 9"
Family Room:
329 sq/ft width 15' 4" x depth 21' 6"
Garage:
516 sq/ft width 21' 6" x depth 24'
Garage Storage:
86 sq/ft width 21' 6" x depth 4'
Kitchen:
121 sq/ft width 8' 6" x depth 14' 3"
Laundry Room:
85 sq/ft width 10' 8" x depth 8'
Master Bathroom:
107 sq/ft width 14' x depth 7' 8"
Master Bedroom:
239 sq/ft width 17' 1" x depth 14'
Patio:
320 sq/ft width 13' 2" x depth 24' 4"
Porch - Front:
187 sq/ft width 22' x depth 8' 6"
Porch - Rear:
173 sq/ft width 20' x depth 8' 8"
What's Included In This Plan Set
- Cover Sheet: Outlines the design criteria and construction notes, such as general site, foundation, framing, and mechanical notes
- Foundation Plan(s): The foundation of your choice (slab or crawlspace - fee may apply)
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. Some plans that do not include an electrical plan may have it available for an additional fee.
- Kitchen Cabinet Elevation(s): Detailed drawings of kitchen cabinet elevations.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Plan Set
$1156.00
$1449.25
$1598.00
$1967.75
Foundation
$0.00
$297.50
$297.50
Framing
$0.00
Additional Options
$255.00
$140.25
$250.75
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
