Key Specs
2094
sq ft
4
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBSUMMER
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 47-828
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 48'
Height : 27'
Width : 56'
Area
Bonus: 378 sq/ft
First Floor: 1360 sq/ft height 8'
Second Floor: 734 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Additional Room Features
Family Room Keeping Room
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
11 sq/ft width 2' x depth 5' 6"
Basement Foundation:
1376 sq/ft width 43' x depth 32'
Bedroom 2:
144 sq/ft width 12' 7" x depth 11' 6"
Bedroom 2 Closet:
18 sq/ft width 2' x depth 9'
Bedroom 3:
120 sq/ft width 10' 6" x depth 11' 6"
Bedroom 3 Closet:
18 sq/ft width 2' x depth 9'
Bedroom 4:
120 sq/ft width 10' 6" x depth 11' 6"
Bedroom 4 Closet:
11 sq/ft width 2' x depth 5' 6"
Bonus Room - Finished:
27 sq/ft width 1' 2" x depth 23' 6"
Breakfast Room:
81 sq/ft width 9' x depth 9'
Crawlspace Foundation:
1376 sq/ft width 43' x depth 32'
Dining Room:
115 sq/ft width 10' x depth 11' 6"
Foyer:
16 sq/ft width 4' 8" x depth 3' 6"
Garage:
493 sq/ft width 21' x depth 23' 6"
Gathering Room:
203 sq/ft width 15' 8" x depth 13'
Hall Bathroom:
57 sq/ft width 5' x depth 11' 6"
Hall Closet:
10 sq/ft width 2' x depth 5'
Kitchen:
115 sq/ft width 10' x depth 11' 6"
Living Room:
189 sq/ft width 12' x depth 15' 10"
Master Bathroom:
99 sq/ft width 8' 8" x depth 11' 6"
Master Bedroom:
183 sq/ft width 12' x depth 15' 4"
Master Closet:
30 sq/ft width 15' 4" x depth 2'
Porch - Front:
160 sq/ft width 5' x depth 32'
Powder Room:
18 sq/ft width 2' 8" x depth 7'
Study:
41 sq/ft width 5' 8" x depth 7' 4"
Utility Room:
58 sq/ft width 8' 4" x depth 7'
What's Included In This Plan Set
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Plan Set
$1013.17
$1130.98
$1248.79
$1248.79
$2026.33
Foundation
$0.00
$0.00
$233.75
$233.75
Framing
$0.00
Additional Options
$165.75
$51.00
$420.75
$127.50
$250.75
$33.15
$127.50
$72.25
$0.00
$845.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
