PLAN 495-4
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 53'
Height : 20'
Width : 40'
Area
Garage : 420 sq/ft
Main Floor : 1940 sq/ft
Upper Floor : 1460 sq/ft
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 12:12
Roof Framing : Slab
Roof Type : Flat
Exterior Wall Framing
Framing : Concrete block
Bedroom Features
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Additional Room Features
Great Room Living Room
Loft
Main Floor Laundry
Storage Area
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Balcony
Covered Front Porch
Grill Deck Sundeck
Structural Information Provided
Foundation Drawing
Structural 1st Floor Framing
Structural Notes
Structural Roof Framing
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: This page shows all necessary notations and dimensions including support columns, walls, and excavated/unexcavated areas.
- Exterior Elevations: Views of the home from all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, etc.
- Cross Section: A slice of the home from roof to foundation, showing important details like stairs and wall construction.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Construction Notes and Details: Shows the builder how things come together, like walls, the chimney, insulation, and more.
Plan Set
$2804.15
$2889.15
$3059.15
$3059.15
$3144.15
$2719.15
Foundation
$0.00
Additional Options
$42.50
$85.00
$33.15
$85.00
$0.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
