Key Specs
2389
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBSUMMER
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 47-723
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 39'
Height : 27'
Width : 70'
Area
First Floor: 1371 sq/ft height 8'
Second Floor: 1018 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Combination Truss/Conventional
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Outdoor Spaces
Covered Front Porch
Rooms
3rd BR Closet:
11 sq/ft width 5' 6" x depth 2'
Attic:
275 sq/ft width 25' x depth 11'
Basement Foundation:
1430 sq/ft width 29' 6" x depth 48' 6"
Bathroom 3:
42 sq/ft width 8' x depth 5' 4"
Bedroom 2:
115 sq/ft width 10' 5" x depth 11' 1"
Bedroom 2 Closet:
14 sq/ft width 7' x depth 2'
Bedroom 3:
121 sq/ft width 11' 7" x depth 10' 6"
Bedroom 3 Closet:
14 sq/ft width 7' x depth 2'
Breakfast Room:
170 sq/ft width 16' 6" x depth 10' 4"
Crawlspace Foundation:
1430 sq/ft width 29' 6" x depth 48' 6"
Den/Office or Bedroom 1:
97 sq/ft width 9' 2" x depth 10' 7"
Dining Room:
125 sq/ft width 11' 6" x depth 10' 11"
Foyer:
123 sq/ft width 16' 6" x depth 7' 6"
Garage:
525 sq/ft width 25' x depth 21'
Gathering Room:
225 sq/ft width 16' 6" x depth 13' 8"
Hall Bathroom:
66 sq/ft width 8' 4" x depth 8'
Hall Closet:
9 sq/ft width 4' 11" x depth 2'
Kitchen:
118 sq/ft width 11' 6" x depth 10' 4"
Living Room:
225 sq/ft width 16' 6" x depth 13' 8"
Master Bathroom:
119 sq/ft width 13' 4" x depth 9'
Master Bedroom:
187 sq/ft width 14' x depth 13' 5"
Porch - Front:
167 sq/ft width 4' 6" x depth 37' 4"
Utility Room:
80 sq/ft width 7' 7" x depth 10' 8"
Walk-In Closet:
47 sq/ft width 8' 1" x depth 5' 10"
What's Included In This Plan Set
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Plan Set
$1013.17
$1130.98
$1248.79
$1248.79
$2026.33
Foundation
$0.00
$0.00
$233.75
$233.75
Framing
$0.00
Additional Options
$165.75
$51.00
$420.75
$127.50
$250.75
$33.15
$127.50
$72.25
$0.00
$845.75
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
