PLAN 927-466
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 41' 6"
Height : 34'
Width : 59' 4"
Area
Basement Unfinished: 1280 sq/ft
First Floor: 1280 sq/ft
Garage: 540 sq/ft
Second Floor: 1204 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick/Stucco
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Unfinished Future Space
Vaulted / Cathedral Ceilings
Workshop
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
width 12' x depth 12' 2"
Bedroom 3:
width 12' x depth 11' 2"
Bedroom 4:
width 12' x depth 11' 8"
Breakfast Nook:
width 10' x depth 13'
Dining:
width 14' 6" x depth 11' 2"
Family Room:
width 14' 6" x depth 20'
Foyer:
width 7' 8" x depth 11'
Garage:
540 sq/ft width 19' 5" x depth 26' 5"
Kitchen:
width 12' 6" x depth 11' 3"
Laundry:
width 6' 2" x depth 5' 9"
Living Room:
width 14' 6" x depth 11' 8"
Master Bath:
width 10' x depth 11'
Master Bedroom:
width 17' x depth 15'
Master Closet:
width 7' 2" x depth 10' 9"
Master Sitting:
width 12' x depth 12' 2"
What's Included In This Plan Set
-
All plans include the front elevation at 1/4" or 3/16" and the sides and rear elevations at 1/8" scale. These elevations show and note the exterior finished materials of the house.
- Every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors). The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls. These plans are completed with dimensions, notes, and door/window sizes. Crawl space and/or slab on grade foundations are available for some plans. All foundation types are not available for all plans.
- Each plan consists of 1/4" or 3/16" scale floor layouts showing the location of 2x4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
- The building sections are drawings which take vertical cuts through the house and the stairs showing floor, ceiling and roof height information.
- The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer. Details are included for many interior and exterior conditions to provide more specific information for their construction.
- Each floor framing plan shows each floor joist indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Each framing plan sheet includes any framing details that are needed (tray details, connection details, etc.). All of the framing is designed using conventional 2 X 10 floor joist or wood I-Joist, depending on the span conditions of each home plan. Framing plans are not available for all home plans.
- The ceiling joist framing plan shows each ceiling joist indicating the size,spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- The roof framing plan shows each rafter, valley, hip and ridge indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- Each plan order includes one set of typical detail sheets that show foundation details, typical wall sections and other framing details. Also included on the detail sheets are miscellaneous interior trim and fireplace details that can be used to customize the home.
Plan Set
$1596.00
$1756.00
$1876.00
$2036.00
$2236.00
Foundation
$0.00
$0.00
Framing
$0.00
Additional Options
$236.00
$132.00
$236.00
$31.20
$132.00
$68.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
