Key Specs
2532
sq ft
3
Beds
2.5
Baths
2
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2025 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 51-1000
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 49' 8"
Height : 30' 6"
Width : 61' 8"
Area
Basement Unfinished: 1332 sq/ft height 8' 2"
First Floor: 1332 sq/ft height 9'
Garage: 670 sq/ft
Second Floor: 1200 sq/ft height 8'
Roof
Primary Pitch : 9:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
175 sq/ft width 12' 6" x depth 14'
Bedroom 3:
130 sq/ft width 11' x depth 11' 10"
Breakfast:
182 sq/ft width 11' 6" x depth 15' 10"
Dining Room:
143 sq/ft width 11' x depth 13'
Garage:
668 sq/ft width 31' 4" x depth 21' 4"
Great Room:
311 sq/ft width 19' 8" x depth 15' 10"
Kitchen:
150 sq/ft width 10' 6" x depth 14' 4"
Master Bedroom:
256 sq/ft width 16' x depth 16'
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Drawn to 1/4" and 1/8" scale.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Layout: Overhead view of roof showing ridges, valleys, and pitch.
- Note: These plans will not contain an electrical layout.
Plan Set
$1327.70
$1552.10
$1575.90
$2103.75
Foundation
$0.00
$0.00
Framing
$0.00
$212.50
Additional Options
$212.50
$51.00
$140.25
$33.15
$140.25
$42.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
