Key Specs
2538
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 47-732
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 49' 6"
Height : 30'
Width : 47' 6"
Area
First Floor: 1462 sq/ft height 8'
Second Floor: 1076 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Outdoor Spaces
Deck
Rooms
3rd BR Closet:
14 sq/ft width 7' 3" x depth 2'
Basement Foundation:
1944 sq/ft width 40' 6" x depth 48'
Bedroom 2:
226 sq/ft width 13' 6" x depth 16' 9"
Bedroom 2 Closet:
10 sq/ft width 4' 3" x depth 2' 6"
Bedroom 3:
130 sq/ft width 13' x depth 10'
Bedroom 3 Closet:
10 sq/ft width 4' 3" x depth 2' 6"
Breakfast Room:
123 sq/ft width 13' x depth 9' 6"
Crawlspace Foundation:
1944 sq/ft width 40' 6" x depth 48'
Deck:
75 sq/ft width 12' 6" x depth 6'
Dining Room:
130 sq/ft width 13' x depth 10'
Foyer:
158 sq/ft width 11' 2" x depth 14' 2"
Garage:
437 sq/ft width 19' x depth 23'
Gathering Room:
270 sq/ft width 13' 6" x depth 20'
Hall Bathroom:
68 sq/ft width 7' 2" x depth 9' 7"
Hall Closet:
12 sq/ft width 2' x depth 6' 4"
Kitchen:
136 sq/ft width 13' x depth 10' 6"
Living Room:
208 sq/ft width 13' x depth 16'
Master Bathroom:
210 sq/ft width 12' x depth 17' 6"
Master Bedroom:
226 sq/ft width 13' 6" x depth 16' 9"
Master Closet:
52 sq/ft width 8' 4" x depth 6' 4"
Study:
96 sq/ft width 12' x depth 8'
Utility Room:
40 sq/ft width 6' 9" x depth 6'
Wash Room:
18 sq/ft width 6' 9" x depth 2' 9"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1147.61
$1272.35
$1397.09
$1397.09
$2295.22
Foundation
$0.00
$0.00
$247.50
$247.50
Framing
$0.00
Additional Options
$175.50
$54.00
$445.50
$135.00
$445.50
$35.10
$135.00
$76.50
$0.00
$895.50
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
