PLAN 927-184
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Hipped rooflines, multiple gables and arch-topped windows all combine to give
this home plenty of curb appeal. Inside, the two-story foyer is flanked by the
formal dining room and a vaulted living room. The spacious family room features
a fireplace and easy access to the kitchen and bayed breakfast room. A
study or make it a guest suite finishes out this level. Upstairs, two
family bedrooms each with walk-in closets share a hall bath. A bonus room
is available for future development. The master suite offers a lavish private
bath, two walk-in closets and a bayed sitting area.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Full Specs & Features
Dimension
Depth : 52'
Height : 33'
Width : 54' 6"
Height : 33'
Width : 54' 6"
Area
Basement Unfinished: 1548 sq/ft
Bonus: 198 sq/ft
First Floor: 1548 sq/ft height 9'
Garage: 542 sq/ft
Second Floor: 1164 sq/ft
Bonus: 198 sq/ft
First Floor: 1548 sq/ft height 9'
Garage: 542 sq/ft
Second Floor: 1164 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Living Room / Parlor
Formal Living Room / Parlor
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Family Room Keeping Room
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
144 sq/ft width 12' x depth 12'
Bedroom 3:
156 sq/ft width 13' x depth 12'
Bedroom 4:
156 sq/ft width 12' 10" x depth 12' 2"
Bonus Room - Finished:
151 sq/ft width 12' 5" x depth 12' 2"
Breakfast:
143 sq/ft width 13' x depth 11'
Dining Room:
169 sq/ft width 13' x depth 13'
Family Room:
292 sq/ft width 19' 9" x depth 14' 10"
Foyer:
139 sq/ft width 8' x depth 17' 5"
Garage:
520 sq/ft width 20' 5" x depth 25' 6"
Kitchen:
137 sq/ft width 13' x depth 10' 7"
Laundry Room:
30 sq/ft width 5' 8" x depth 5' 4"
Living Room:
153 sq/ft width 11' 8" x depth 13' 2"
Master Bathroom:
145 sq/ft width 11' x depth 13' 3"
Master Bedroom:
238 sq/ft width 16' 8" x depth 14' 4"
Master Closet - Hers:
27 sq/ft width 5' 5" x depth 5' 2"
Master Closet - His:
27 sq/ft width 5' 5" x depth 5' 2"
Master Sitting Room:
97 sq/ft width 13' x depth 7' 6"
What's Included In This Plan Set
- Purchasing a CAD set, PDF set, or Reproducible set, gives you an unlimited build license. All other plan sets, allow you to build the home one time.
- All plans include the front elevation at 1/4" or 3/16" and the sides and rear elevations at 1/8" scale. These elevations show and note the exterior finished materials of the house.
- Every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors). The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls. These plans are completed with dimensions, notes, and door/window sizes. Crawl space and/or slab on grade foundations are available for some plans. All foundation types are not available for all plans.
- Each plan consists of 1/4" or 3/16" scale floor layouts showing the location of 2x4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
- The building sections are drawings which take vertical cuts through the house and the stairs showing floor, ceiling and roof height information.
- The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer. Details are included for many interior and exterior conditions to provide more specific information for their construction.
- Each floor framing plan shows each floor joist indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Each framing plan sheet includes any framing details that are needed (tray details, connection details, etc.). All of the framing is designed using conventional 2 X 10 floor joist or wood I-Joist, depending on the span conditions of each home plan. Framing plans are not available for all home plans.
- The ceiling joist framing plan shows each ceiling joist indicating the size,spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- The roof framing plan shows each rafter, valley, hip and ridge indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- Each plan order includes one set of typical detail sheets that show foundation details, typical wall sections and other framing details. Also included on the detail sheets are miscellaneous interior trim and fireplace details that can be used to customize the home.
