Key Specs


2759
sq ft

4
Beds

3
Baths

2
Floors

3
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Mediterranean Floor Plan - Main Floor Plan Plan #472-192
Floor Plan - Upper Floor Plan
Mediterranean Floor Plan - Upper Floor Plan Plan #472-192

Full Specs & Features


Dimension
Depth : 47' 4"
Height : 29'
Width : 73' 6"
Area
First Floor: 1625 sq/ft
Second Floor: 1134 sq/ft
Roof
Roof Framing : Conventional
Primary Pitch : 9:12
Roof Type : Asphalt
Exterior Wall Framing
Framing : Wood - 2x4
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Fireplace
Kitchen Features
Kitchen Island
Outdoor Spaces
Deck

What's Included In This Plan Set


  • ELECTRICAL SCHEMATIC
  • EXTERIOR ELEVATIONS
  • CABINET ELEVATIONS
  • CEILING FRAMING
  • ROOF FRAMING
  • FOUNDATION OF CHOICE AS AVAILABLE (SLAB, CRAWLSPACE OR BASEMENT) APPROPRIATE FOUNDATION DETAIL SHEET
  • BUILDING CROSS SECTION IF MULTISTORY
  • ALSO 4 PAGE FHA DESCRIPTION OF MATERIALS FORM (NOT A MATERIALS LIST OF QUANTITIES)
  • GENERIC WALL SECTIONS
    Note: Reproducible and CAD files are not available if building in Texas, Oklahoma, New Mexico, or Louisiana. Architect must update and stamp all plans being sent to these states.
