PLAN 47-774
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 81'
Height : 22'
Width : 67' 6"
Area
First Floor: 2966 sq/ft height 10'
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Additional Room Features
Den Office Study Computer
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
3rd BR Closet:
10 sq/ft width 5' x depth 2'
Basement Foundation:
4033 sq/ft width 59' 9" x depth 67' 6"
Bathroom 3:
49 sq/ft width 9' x depth 5' 6"
Bedroom 2:
168 sq/ft width 12' x depth 14'
Bedroom 2 Closet:
8 sq/ft width 4' x depth 2'
Bedroom 3:
168 sq/ft width 12' x depth 14'
Bedroom 3 Closet:
8 sq/ft width 4' x depth 2'
Breakfast Room:
85 sq/ft width 8' 6" x depth 10'
Crawlspace Foundation:
width 0" x depth 2"
Den/Office or Bedroom 1:
141 sq/ft width 11' 9" x depth 12'
Dining Room:
141 sq/ft width 11' 9" x depth 12'
Foyer:
135 sq/ft width 13' 6" x depth 10'
Gathering Room:
257 sq/ft width 19' 10" x depth 13'
Hall Bathroom:
63 sq/ft width 6' 6" x depth 9' 10"
Kitchen:
166 sq/ft width 12' 6" x depth 13' 4"
Living Room:
301 sq/ft width 15' 1" x depth 20'
Master Bathroom:
132 sq/ft width 12' x depth 11'
Master Bedroom:
320 sq/ft width 23' 4" x depth 13' 9"
Porch - Front:
60 sq/ft width 6' x depth 10'
Porch - Rear:
510 sq/ft width 20' x depth 25' 6"
Powder Room:
35 sq/ft width 6' 10" x depth 5' 2"
Utility Room:
78 sq/ft width 12' x depth 6' 6"
Walk-In Closet:
52 sq/ft width 8' x depth 6' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1147.61
$1272.35
$1397.09
$1397.09
$2295.22
Foundation
$0.00
$0.00
$247.50
$247.50
Framing
$0.00
Additional Options
$175.50
$54.00
$445.50
$135.00
$445.50
$35.10
$135.00
$76.50
$0.00
$895.50
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
