PLAN 51-1110
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55'
Height : 31' 6"
Width : 95' 5"
Area
First Floor: 1655 sq/ft height 9'
Garage: 933 sq/ft height 9'
Second Floor: 1495 sq/ft height 8'
Roof
Primary Pitch : 9:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Mud Room
Sunroom
Outdoor Spaces
Covered Front Porch
Screened Porch
Rooms
Bedroom 2:
154 sq/ft width 12' 6" x depth 12' 4"
Bedroom 3:
131 sq/ft width 10' 8" x depth 12' 4"
Bedroom 4:
176 sq/ft width 14' 4" x depth 12' 4"
Dinette:
188 sq/ft width 11' 4" x depth 16' 8"
Dining Room:
160 sq/ft width 13' 2" x depth 12' 2"
Garage:
859 sq/ft width 36' 4" x depth 23' 8"
Great Room:
271 sq/ft width 17' 2" x depth 15' 10"
Kitchen:
240 sq/ft width 13' 6" x depth 17' 10"
Library:
111 sq/ft width 9' 10" x depth 11' 4"
Master Suite:
211 sq/ft width 13' 4" x depth 15' 10"
Master Walk-In Closet:
55 sq/ft width 6' 10" x depth 8' 2"
Parlor:
166 sq/ft width 13' 4" x depth 12' 6"
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Drawn to 1/4" and 1/8" scale.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Layout: Overhead view of roof showing ridges, valleys, and pitch.
- Note: These plans will not contain an electrical layout.
Plan Set
$1500.00
$1750.00
$1775.00
$2300.00
Foundation
$0.00
Framing
$0.00
$250.00
Additional Options
$250.00
$60.00
$165.00
$39.00
$165.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
