PLAN 14-255
Key Specs
3440
sq ft
4
Beds
3.5
Baths
2
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 14-255
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 27'
Width : 76'
First Floor: 2146 sq/ft height 9'
Garage: 555 sq/ft height 9'
Porch: 758 sq/ft
Second Floor: 1039 sq/ft height 9'
Main Ceiling : 9'
Roof Framing : Conventional
Secondary Pitch : 12:12
Framing : 2"x6"
Bathroom 2:
9 sq/ft width 1' 8" x depth 5' 6"
Bathroom 3:
63 sq/ft width 11' 6" x depth 5' 6"
Bedroom 2:
175 sq/ft width 14' x depth 12' 6"
Bedroom 2 Closet:
21 sq/ft width 8' 6" x depth 2' 6"
Bedroom 3:
189 sq/ft width 14' x depth 13' 6"
Bedroom 3 Closet:
21 sq/ft width 8' 6" x depth 2' 6"
Bedroom 4:
178 sq/ft width 14' x depth 12' 9"
Bedroom 4 Closet:
37 sq/ft width 6' 9" x depth 5' 6"
Bonus Room - Finished:
252 sq/ft width 12' x depth 21'
Breakfast Room:
132 sq/ft width 11' x depth 12'
Dining Room:
195 sq/ft width 13' 6" x depth 14' 6"
Foyer:
109 sq/ft width 6' x depth 18' 2"
Garage:
544 sq/ft width 24' x depth 22' 8"
Great Room:
389 sq/ft width 17' 10" x depth 21' 10"
Half Bathroom:
23 sq/ft width 4' 4" x depth 5' 6"
Kitchen:
225 sq/ft width 19' 2" x depth 11' 9"
Laundry Room:
55 sq/ft width 9' 8" x depth 5' 9"
Living Room:
146 sq/ft width 13' 6" x depth 10' 10"
Master Bathroom:
344 sq/ft width 22' x depth 15' 8"
Master Bedroom:
281 sq/ft width 15' 6" x depth 18' 2"
Master Closet:
34 sq/ft width 6' x depth 5' 10"
Master Closet Two:
52 sq/ft width 9' x depth 5' 10"
Porch - Front:
198 sq/ft width 33' x depth 6'
Porch - Left:
121 sq/ft width 6' x depth 20' 4"
Porch - Rear:
385 sq/ft width 38' 6" x depth 10'
Porch - Right:
135 sq/ft width 6' x depth 22' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
