Full Specs & Features
Depth : 63' 6"
Height : 31' 6"
Width : 64' 6"
First Floor: 2716 sq/ft
Garage: 537 sq/ft
Second Floor: 960 sq/ft
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Tile
Exterior Wall Framing
Exterior Wall Finish : Stucco
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Open Floor Plan
Vaulted / Cathedral Ceilings
176 sq/ft width 11' x depth 16'
198 sq/ft width 13' 8" x depth 14' 6"
149 sq/ft width 11' 10" x depth 12' 8"
180 sq/ft width 12' x depth 15'
183 sq/ft width 12' x depth 15' 4"
360 sq/ft width 17' 2" x depth 21'
491 sq/ft width 22' 4" x depth 22'
245 sq/ft width 15' 4" x depth 16'
230 sq/ft width 13' 8" x depth 16' 10"
289 sq/ft width 15' x depth 19' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
